Hot Rolled Steel Coil/cold Rolled or Hot Rolled Steel Coil

US$ 600 - 750 MOQ: 50 Metric Tons

Key Specifications

Standard:

JIS, AISI, ASTM, GB, AISI, ASTM, Other, DIN, JIS, AISI, ASTM, GB, AISI,ASTM,BS,DIN

Length:

Strip

Thickness:

0.08-1.0mm, 0.8-6mm

Tianjin Goldensun Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang China

Delivery Detail:

Delivery time depends on order quantity.

Standard JIS, AISI, ASTM, GB, AISI, ASTM, Other, DIN, JIS, AISI, ASTM, GB, AISI,ASTM,BS,DIN

Length Strip

Thickness 0.08-1.0mm, 0.8-6mm

Width 50-1200mm, 75-1500,50-1200mm

Place of Origin Tianjin, China

Type Coil

Certification ISO

Application steel pipe making

Model Number 50mm-1200mm

Specifications

Hot rolled steel coil/cold rolled or hot rolled steel coil
Thickness : 0.15*1.5mm
Width: 10-800mm

Hot rolled steel coil/cold rolled or hot rolled steel coil

The specifications :

Grade		Q195/215/235B/345B/20Mn steel SGCC DX51D DX53D DX54D
Standard		GB AISI ASTM BS DIN JIS
Thickness		0.05 MM - 3.00 MM
Width		10 MM – 800MM
Zinc Coating		30g/m2 - 275g/m2
Length/weight		Depend on the coil
Inner Diameter		Ribbon wound=200mm/300mm/406mm Oscillated wound=406mm
Tensile Strength		280 – 430Mpa
Technique		Hot rolled/Cold rolled- Galvanized (Zinc coated)
Spangle State		Mini/Regular/Big/Zero spangle
Surface Treatment		Chromate treatment /Chromate-free treatment Untreated Un-oiled/Oiled Anti-fingerprint/Un-Anti-fingerprint Coating, Color, Bluing treatment, Heat Treatment
Note: We can produce special specification as per customer request, and we can make the edge smoother of the steel packing strips.
Tolerances	Width		≤31.75mm		± 0.10mm
			>31.75mm		±0.13mm
	Thickness		≤0.40mm		±0.015mm
			>0.40—0.70mm		±0.020mm
			>0.70—1.30mm		±0.025mm
Note: The thickness of steel strip does not include the coating or the thickness of the max.
Technical Parameters	Ordinary steel strapping			σb≥65-75kg/mm2(650-750Mpa), elongation:δ5≥3%-5%
	Ordinary steel strapping			σb≥75-85kg/mm2(750-850Mpa), elongation:δ5≥4%-6%
	High quality steel strapping			σb≥85-1000kg/mm2(8501000Mpa), elongation:δ5≥5-8%
