Contact Platform Support
Help CenterH-beam
US$ 450 - 1,000
MOQ: 25 Tons
Key Specifications
Get Latest Price
Place of Origin:
Tianjin, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Tianjin, China
Specifications
Hot rolling H steel (GB1263-89) also called the wide leg I-steel, rolled by H section mill with the belt side.| sequence | H(mm) | B(mm) | T1(mm)9 | T2(mm) | R(mm) | unit weight(kg/m) | sectional area(cm2) |
| 01 | 175 | 175 | 7.5 | 11 | 13 | 40.4 | 51.43 |
| 02 | 200 | 200 | 8 | 12 | 13 | 49.9 | 63.53 |
| 03 | 200 | 204 | 12 | 12 | 13 | 56.2 | 71.53 |
| 04 | 244 | 252 | 11 | 11 | 13 | 63.8 | 81.31 |
| 05 | 250 | 255 | 14 | 14 | 13 | 81.6 | 103.93 |
| 06 | 250 | 250 | 9 | 14 | 13 | 71.8 | 91.43 |
| 07 | 294 | 200 | 8 | 12 | 13 | 55.8 | 71.05 |
| 08 | 340 | 250 | 9 | 14 | 13 | 78.1 | 99.53 |
| 09 | 300 | 150 | 6.5 | 9 | 13 | 36.7 | 46.78 |
| 10 | 298 | 149 | 5.5 | 8 | 13 | 32.0 | 40.80 |
| 11 | 346 | 174 | 6 | 9 | 13 | 41.2 | 52.45 |
| 12 | 350 | 175 | 7 | 11 | 13 | 49.4 | 62.91 |
| 13 | 396 | 199 | 7 | 11 | 13 | 56.1 | 71.41 |
| 14 | 400 | 200 | 8 | 13 | 13 | 65.4 | 83.37 |
| 15 | 446 | 199 | 8 | 12 | 13 | 65.1 | 82.97 |
| 16 | 450 | 200 | 9 | 14 | 13 | 74.9 | 95.43 |
| 17 | 496 | 199 | 9 | 14 | 13 | 77.9 | 99.29 |
| 18 | 500 | 200 | 10 | 16 | 13 | 88.1 | 112.25 |
dimension lable:
H:hight
B:breadth of flange
T1:thickness of tube sopport plate
T2:thickness of flange
R:angular radius
