SD/LD/KM Type Single Cylinder Engine Diesel

SD/LD/KM Type Single Cylinder Engine Diesel thumbnail-1
SD/LD/KM Type Single Cylinder Engine Diesel photo-1
US$ 218 - 330 MOQ: 84 Sets
Key Specifications
Get Latest Price
Type:
Other, complete engine
Use:
Tractors
Place of Origin:
Shandong, China
Contact Supplier Request Quote Chat Now
Shandong Liaocheng Yitong Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, complete engine
Use Tractors
Place of Origin Shandong, China
Brand Name XINYA
Model Number engine diesel

Specifications

1.SD type/ LD type/ KM type diesel engine
able of single cylinder engine diesel
3.low price best price
4OEM offer



Diesel Engine Specification

 1.20 HP  single cylinder engine diesel

2.195kg to 230kg net weight

able goods

4.stable performance

5.low price with high quality

6.welcome to our factory buy diesel engine



Diesel Engine Details



         Model                   specification Unit
SD195 SD1100 SD1100B SD1105 SD1110 SD1110L SD1115
Type Horizontal type, single, cylinder, four-stork, water-cooling
Cylinder diameter × stroke mm 95×115 100×115 100×115 105×115 110×115 110×125 115×125
Displacement L 0.815 0.903 0.093 0.996 1.093 1.18 1.298
Model of combustion chamber   Swirl chamber Direct-injection
Compressure chamber   19~20 20 20 16.5 16.5 17.5 17.5
Power 1 Hour Power kw/r(min) 9.7/2200 12.1/2200 12.1/2200 13/2200 14.7/2200 16.17/2200 17.6/2200
12 Hour Power kw/r(min) 8.8/2200 11/2200 11/2200 11.76/2200 13.2/2200 14.66/2200 16.2/2200
Specific fuel consumption g/kw.h ≤262.5 ≤262.5 ≤262.5 ≤250.2 ≤250.2 ≤250.2 ≤250.2
Specific oil consumption kg/h ≤0.024 ≤0.030 ≤0.030 ≤0.032 ≤0.036 ≤0.040 ≤0.044
Max torque N.m ≥47.06 ≥53.4 ≥53.4 ≥57.1 ≥64.1 ≥71.4 ≥78.7
Lubricating method Combined pressure and splashing
Cooling method Water-cooling or hopper cooling
Starting method Hand Cranking or electric starting
Net weight Kg 195 200 200 215 220 225 230
Overall dimension mm 820 x 530 x750 820 x 530 x750 820 x 530 x750 820 x 530 x750 820 x 530 x750 820 x 530 x750 820x530x750
length×width×height 880x530x750



Photo Shows for Reference

SD/LD/KM Type Single Cylinder Engine DieselSD/LD/KM Type Single Cylinder Engine Diesel

SD/LD/KM Type Single Cylinder Engine Diesel



Product Payment Terms

 1.A ccepted small order.

2.Ready to delivery by sea, TNT,DHL,as soon as receipt of payment.

3.We accept T/T,Western Union, L/C.



Mission & Objective of Yitong

1.Zero Defect Quality,Zero Customer Complaints

2.To be a best professional supplier in the line of diesel engine parts.



Our Promises

1.Reply to your inquiries in 3 working hours

2.Your detail requirement will be responded within 24 hours.

3.Your needs will always be treated as our our top priority.

4.Keep contacting until the goods arrived safely.

5.You can contact me any time while you have questions and demands.

 SD/LD/KM Type Single Cylinder Engine Diesel
