Help CenterLD Series Single Cylinder Agriculture Diesel Engine
Related Products
Specifications
1.LD1110/LD11152.farm machine and harvest machine
3.green diesel
4.low fuel consumption
| ITEM NAME |
LD series single cylinder agriculture diesel engine
1.LD1110 / LD1115
2.type:horizontal type; single; cylinder; four stork; water-cooling.
3.mainly export to more than 20 contries and regions like USA, ITALY, PERU,INDONESIA, SWITZERLAND etc.
4.Qualified in authentication of ISO/TS16949 Quality Certification System.
| LIST FOR YOUR REFERENCE |
| The Model of LD Diesel Engine | ||||||
| Model Specification | ||||||
| Unit | LD1110 | LD1115 | KM130 | KM138 | ||
| Type | Horizontal type, single, cylinder, four-stork, water-cooling | |||||
| Cylinder diameter × stroke | mm | 110×115 | 115×115 | 118×118 | 122×118 | |
| Displacement | L | 1.093 | 1.194 | 1.29 | 1.38 | |
| Model of combustion chamber | Direct-injection | |||||
| Compressure chamber | 16~18 | 16~18 | 17 | 17 | ||
| 1 Hour Power | kw/r(min) | 14.7/2200 | 16.2/2200 | 17.6/2200 | 18.4/2200 | |
| Power | ||||||
| 12 Hour Power | kw/r(min) | 13.2/2200 | 14.7/2200 | 16.2/2200 | 17.6/2200 | |
| Specific fuel consumption | g/kw.h | ≤242.1 | ≤242.1 | ≤242.1 | ≤242.1 | |
| Specific oil consumption | kg/h | ≤0.036 | ≤0.040 | ≤0.044 | ≤0.048 | |
| Max torque | N.m | ≥64.2 | ≥78.8 | ≥85.6 | ≥89.4 | |
| Lubricating method | Combined pressure and splashing | |||||
| Cooling method | Water-cooling or hopper cooling | |||||
| Starting method | Cranking or electric starting | |||||
| Net weight | Kg | 230 | 230 | 230 | 230 | |
| Overall dimension | mm | 820 x 530 x 750 | 820 x 530 x 750 | 820 x 530 x 750 | 820 x 530 x 750 | |
| length×width×height | ||||||
| PHOTO SHOWS FOR REFERENCE |
| PACKAGE & DELIVERY |
1.packing with wooden case
2.Large orders will be arranged production ASAP.
3.Small order is available and delivered within 15 working days.
| EXCELLENT SERVICE |
1.Youy inquiry will be replyed within 2 working hours.
2.Any question will be answered patiently
3.Any quality problem will be solved during the quality guarante period.
3.Keep contacting until the products arrived safely.
"STABLE QUALITY, PUNCTUAL DELIVERY, REASONABLE PRICE AND BEST SERVICE "ALWAYS STAND AS OUR MISSION
