Single Cylinder Diesel Engine
Specifications
1 specialization in production2 reasonable price with stable performence
3 get ISO/TS 16949 certificate
4 quick shipment
we could provide single cylinder diesel engine in farming such as LD1110 LD1115 KM130 KM138 KM176 KM186.
|
Model Specification |
Unit |
LD1110 |
LD1115 |
KM130 |
KM138 |
|
Type |
Horizontal type, single, cylinder, four-stork, water-cooling |
|||||
Cylinder diameter × stroke |
mm |
110×115 |
115×115 |
118×118 |
122×118 |
|
Displacement |
L |
1.093 |
1.194 |
1.29 |
1.38 |
|
Model of combustion chamber |
Direct-injection |
|||||
Compressure chamber |
16~18 |
16~18 |
17 |
17 |
||
|
Power
|
1 Hour Power |
kw/r(min) |
14.7/2200 |
16.2/2200 |
17.6/2200 |
18.4/2200 |
12 Hour Power |
kw/r(min) |
13.2/2200 |
14.7/2200 |
16.2/2200 |
17.6/2200 |
|
Specific fuel consumption |
g/kw.h |
≤242.1 |
≤242.1 |
≤242.1 |
≤242.1 |
|
Specific oil consumption |
kg/h |
≤0.036 |
≤0.040 |
≤0.044 |
≤0.048 |
|
Max torque |
N.m |
≥64.2 |
≥78.8 |
≥85.6 |
≥89.4 |
|
Lubricating method |
Combined pressure and splashing |
|||||
Cooling method |
Water-cooling or hopper cooling |
|||||
Starting method |
Cranking or electric starting |
|||||
Net weight |
Kg |
230 |
230 |
230 |
230 |
|
|
Overall dimension length×width×height |
mm |
820 x 530 x 750 |
820 x 530 x 750 |
820 x 530 x 750 |
820 x 530 x 750 |
|
