introduction
Mixing is a very important unit operation in chemical industry, metallurgy, food, feed and other industries widely used, especially in the most used in chemical industry.Stir to make material mix, strengthen the mass transfer, heat transfer, is an important means of promoting chemical reactions and dispersed emulsion
The equipment compact structure, good sealing, mixing strong uniform particle size, solid phase segregation, heavy tank, also can make gas stirring;
Our company's mining churn advanced equipment performance, product quality is stable, stir well, discharge rapidly, have very good reputation in the industry, is definitely your first choice
work principle
It is suitable for the concentration is not more than 30% and ore pulp density is not greater than 3.5 and the mixing of flotation reagents.Work, under the effect of the rotation of the impeller, the pulp and medicament produce large and small cycle movement, so that the entire groove to pulp, medicament, uniform blending of suspension of the overflow mouth eduction
Technical Data
| Specification | Chute inner dimension |
Effective cubage (m³) |
Mixer | Motor |
Total weight (kg) |
|||
|
Diameter (mm) |
Depth (mm) |
Diameter (mm) |
Rotate speed (r/min) |
Model |
Power (kw) |
|||
| XB-750 | 750 | 750 | 0.26 | 240 | 530 | Y90S-4 | 1.1 | 550 |
| XB-1000 | 1000 | 1000 | 0.58 | 240 | 530 | Y90L-4 | 1.5 | 700 |
| XB-1200 | 1200 | 1200 | 1.14 | 400 | 320 | Y100L2-4 | 3 | 980 |
| XB-1500 | 1500 | 1500 | 2.2 | 400 | 320 | Y100L2-4 | 3 | 1330 |
| XB-2000 | 2000 | 2000 | 5.46 | 550 | 230 | Y132M2-6 | 5.5 | 2100 |
| XB-2500 | 2500 | 2500 | 11.2 | 650 | 200 | Y160L-6 | 11 | 3438 |
| XB-3000 | 3000 | 3000 | 19.1 | 700 | 210 | Y225S-8 | 18.5 | 5100 |
| XB-3500 | 3500 | 3500 | 30 | 850 | 230 | Y225M-8 | 22 | 7900 |
