Specifications
Ball mill:1. low energy consuming
2. easy operation and installation
3. convenient maintenance
4. high efficiency
globe ball grinding mill for sale China supplier with ex-factory price
Small ball mill for sale:
Ball mill price is the main part of our service. We calculate the ball mill price as per to quality and the after sale service. For different size different material will give you different ball mill price.
Small ball mill introduction:
The ball mill is a key equipment for grinding materials, widely used in powder-making production line such as cement, silicate sand, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics, etc.
Ball mill can grind various ores and materials with dry type or wet type. There are two kinds of ball mills, grate type and overfall type due to different ways of discharging material.
Small ball mill working principle:
The ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.
Technical data:
Model |
Speed of bucket(r/min) |
Weightof ball |
Size offeed opening(mm) |
Production(t/h) |
Power(kw) |
Weight(T) |
900×1800 |
38 |
1.5 |
≤20 |
0.65-2 |
18.5 |
3.6 |
900×3000 |
38 |
2.7 |
≤20 |
1.1-3.5 |
22 |
4.6 |
1200×2400 |
32 |
3.8 |
≤25 |
1.5-4.8 |
45 |
12.5 |
1200×3000 |
32 |
5 |
≤25 |
1.6-5 |
45 |
12.8 |
1500×3000 |
27 |
8 |
≤25 |
2-5 |
90 |
17 |
1500×5700 |
27 |
15 |
≤25 |
3.5-6 |
132 |
24.7 |
1830×3000 |
24 |
11 |
≤25 |
4-10 |
180 |
28 |
2200×5500 |
21 |
30 |
≤25 |
10-22 |
370 |
48.5 |
2200×6500 |
21 |
30 |
≤25 |
14-26 |
280 |
52.8 |
2200×7500 |
21 |
33 |
≤25 |
16-29 |
475 |
56 |
Note: This specification is just reference, any changes are subject to the products. We canproduce the equipment as your special requirement.
Our service:
Mining machines design and manufacture.
Technical engineer is available to the construction site for installation instruction and trial operation.
Customization is available.
Why Choose Us?
We are the manufactory, we can provide you ex-factory price;
Strictly quality control system;
Professional technical online service;
Any mail or message will be replied within 8 hours;
Completive manufactory price;
We have many large ore dressing line;
We will provide equipment operation training for our client;
We have a professional after-sale service team to promptly solve your problems.
Welcome to visit our factory!
