Help CenterPA12 Tube
Related Products
Specifications
1. Material: PA122. good impact at lower temperature.
3. better recover feature.
4. stable water abosrption
PA12 tube
Since it first came on the market in 1930s, nylon (polyamide) has found applications in textile, automotive, pipe, hose, tube, fuel lines, fittings, sporting goods and more. Due to nylon's light weight, good pressure & temperature ratings and excellent abrasion resistance, nylon tube became a very important material for air & liquids transfer system.
Applications of nylon tube: automotive, pneumatic systems, air & oil transfer, industrial equipment and more.
As one manufacturer, we offer many metric and imperial sizes, in many standard colors.
Following are the detailed specifications of our nylon tube, if you need help in selecting the right products which are suitable for your application, or if you have any questions , please email to us , we would reply to you within 12 hours.
Specifications:
Available colors: black, yellow, red, blue, green and natural.
Standard length: 25meter coils, 30meter coils, 50meter coils and 100meter coils
Size |
O.D |
Wall |
Working Pressure |
Burst Pressure MPa |
Bend Radius mm |
Φ3*0.5 |
3mm |
0.5mm |
3.0 |
4.5 |
18 |
Φ4*0.75 |
4mm |
0.75mm |
3.1 |
5.5 |
20 |
Φ4*1 |
4mm |
1mm |
4.5 |
6.8 |
30 |
Φ5*1 |
5mm |
1mm |
3.4 |
6.5 |
35 |
Φ6*1 |
6mm |
1mm |
3.2 |
6.3 |
40 |
Φ8*1 |
8mm |
1mm |
2.5 |
5.7 |
50 |
Φ10*1 |
10mm |
1mm |
2.6 |
4.5 |
65 |
Φ10*1.25 |
10mm |
1.25mm |
2.7 |
5.7 |
65 |
Φ12*1.5 |
12mm |
1.5mm |
2.8 |
5.7 |
70 |
Φ14*1.5 |
14mm |
1.5mm |
2.0 |
5.7 |
80 |
Φ16*2 |
16mm |
2mm |
2.5 |
5.7 |
130 |
Φ18*1.5 |
18mm |
1.5mm |
1.8 |
3.6 |
155 |
Φ23*2 |
23mm |
2mm |
1.7 |
3.3 |
120 |
1/4" |
1/4" |
0.04" |
3.2 |
6.3 |
40 |
5/16" |
5/16" |
0.04" |
2.7 |
6.0 |
50 |
3/8" |
3/8" |
0.059" |
2.6 |
4.5 |
65 |
1/2" |
1/2" |
0.059" |
2.5 |
5.0 |
70 |
