Electric / Hydraulic Anchor Windlass
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Sinma
Model Number:
HAW
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangsu, China
Brand Name
Sinma
Model Number
HAW
Power Source
Electric
Application
Boat
Capacity
50 tons
Specifications
suitable for 16-147mm Chain Size Availablewith class cert.
Specifications:
1) Drive: electric / hydraulic
2) Configuration: single in vertical / horizontal arrangement / double gypsies in horizontal
3) Chain size: 16 mm to 127 mm
4) Chain speed: complying with ISO requirements
5) Clutch: manually operated dog clutch
6) Brake: manually and hydraulic operated band brake
7) Control: local control
8) Paint: as per your specifications
| Anchor Windlass (16-44mm Chain) | |||||||
| Model No | Chain Sizemm GR2 | Gypsies Test Pull(MT) | Gypsies Rated Pull(MT) | Gypsies Brake Holding (Static MT) | Gypsies Centre to Centre mm | Double Warping head Size(dia)mm | Power (kW) Approx. |
| AW/GG-12.5 | 12.5 | 1 | 0.7 | 4.2 | 600/800 | 150 | 3 |
| AW/GG-14 | 14 | 1.3 | 0.9 | 5.1 | 600/800 | 150 | 3.7 |
| AW/GG-16 | 16 | 1.7 | 1.1 | 6.9 | 800/1000 | 150 | 4 |
| AW/GG-17.5 | 17.5 | 2 | 1.3 | 8.2 | 800/1000 | 250 | 5.5 |
| AW/GG-19 | 19 | 2.4 | 1.6 | 9.7 | 1000/1200 | 300 | 7 |
| AW/GG-20.5 | 20.5 | 2.7 | 1.9 | 11.2 | 1000/1200 | 300 | 7.5 |
| AW/GG-22 | 22 | 3.2 | 2.1 | 12.9 | 1000/1500 | 300 | 11 |
| AW/GG-24 | 24 | 3.8 | 2.5 | 15.3 | 1000/1500 | 300 | 11 |
| AW/GG-26 | 26 | 4.4 | 2.9 | 17.9 | 1200/1500 | 300 | 11 |
| AW/GG-28 | 28 | 5.1 | 3.4 | 20.6 | 1200/1500 | 330 | 15 |
| AW/GG-30 | 30 | 5.9 | 3.9 | 23.6 | 1200/1500 | 330 | 15 |
| AW/GG-32 | 32 | 6.6 | 4.4 | 26.7 | 1200/1500 | 330 | 18.5 |
| AW/GG-34 | 34 | 7.5 | 5 | 30.1 | 1500/2000 | 380 | 18.5 |
| AW/GG-36 | 36 | 8.4 | 5.6 | 33.6 | 1500/2000 | 380 | 22 |
| AW/GG-40 | 40 | 10.4 | 6.9 | 41.1 | 1800/2000 | 380 | 30 |
| AW/GG-42 | 42 | 11.4 | 7.6 | 45.1 | 1800/2000 | 380 | 30 |
| AW/GG-44 | 44 | 12.8 | 8.4 | 49.5 | 1800/2000 | 380 | 30 |
