Specifications
1.24-port L3 managed 100M Fast Ethernet Switch2.Cost-Advantageous Gigabit to the Desktop Solution
24-port Layer 3 managed 100M Fast Ethernet Switch ES-4124
Introduction
Ethernet switch ES-4124 is intelligent multilayer (L2/L3/L4) Ethernet switches providing enterprise-class availability, resilient and redundant architecture with OSPF, VRRP, RSTP and port trunking. This type offers many advanced features that make it the preferred choice for realrouting enterprise networks. Advanced functionalities like QoS, ratelimiting,rulebased access control lists, multicasting support, wirespeed, highperformance IP routing and simplified management software (iStacking) all contribute to the excellent efficiency of network operations.
Key Benefits
Ideal for Multi-service Network Environment
Ethernet switch ES-4124 delivers fully dynamic wire-speed IP routing features like OSPFv2 and RIPv2 using a hardware-based IP routing engine, as well as sophisticated multilayer operating software that quickly and precisely transmits Layer-3 traffics without packet loss or latency. In addition to dynamic IP routing, this type supports DVMRP, IGMPv3 and MVR for most applications on today’s IP-based multimedia platforms. With this type, enterprises can easily employ applications such as IP TV, video conferencing and distant learning.
Intelligent QoS for Mission-critical Applications
With more and more applications integrated into IP-based networks, the network traffic flows become more and more complicated and diverse than ever. To assure the multi-service quality on a converged network, adopting advanced traffic control technologies to manage different type of traffic flows is critical and necessary to enterprises. This type supports Intelligent QoS features to optimize network traffics. With supports to Class of Service (CoS) and Differentiated Services Code Point (DSCP), administrator can easily classify and perform traffic prioritization for business-critical applications such as VoIP and video conferencing. In addition, this type provides advanced bandwidth control with granularity of 64 kbps and 8 hardware priority queues to bring better bandwidth administration to network operators.
Hassle-free Network Management and 24-Unit Stacking Capability
Ethernet switch provides various network management options. Networking administrators have the freedom to choose the friendly Webbased configuration or the convenient text-based CLI (Command Line Interface) to manage the switch. Since this type supports centralized SNMP-based management software, maintenance can be performed remotely. This type also supports the exclusive iStackingTM clustering management technology that works across different floors and routing domains to locate other iStacking-capable switches in the same cluster, allowing administrators to manage up to 24 switches with one single IP. This greatly reduces operating costs and offers flexible maintenance to switches.
Specification
Operating Temperature 0°C ~ 45°C
Storage Temperature -25°C ~ 70°C
Operating Humidity 10% ~ 90%, (non-condensing)
Standard Compliance
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100 Base-Tx Ethernet
IEEE 802.ab 1000 Base-T Ethernet
IEEE 802.3z
IEEE 802.3x flow control
IEEE 802.1D spanning tree protocol
IEEE 802.1w rapid spanning tree protocol
IEEE 802.1s multiple spanning tree protocol
IEEE 802.1p class of service, priority protocols
IEEE 802.1Q VLAN tagging
IEEE 802.1x port authentication
IEEE 802.3ad LACP aggregation
IEEE 802.1ad VLAN stacking
Certification
UL 60950-1
CSA 60950-1
EN 60950-1
IEC 60950-1
EU RoHS compliant
