HUAWEI IP55 cabinet F01S200 outdoor cabinet FTTH cabinet

Product Overview



SmartAX F Series Outdoor Cabinet



SmartAX F series outdoor cabinets provide Fiber-To-The-Curb (FTTC), Fiber-To-The-Building (FTTB), Fiber-To-The-Office (FTTO), and Fiber-To-The-Home (FTTH) outside devices. SmartAX F series products can mount on a wall, pole, base, or elevated platform.

This one-stop outdoor solution for customers includes a cabinet, power system, Main Distribution Frame (MDF), Optical Distribution Frame (ODF), battery, environment monitoring and temperature control modules.

Flexibility and easy installation make the SmartAX F series suitable for just about any outdoor deployment.

Features



Huawei SmartAX F series outdoor cabinet solution provides one-stop delivery for fast site deployment, efficient power consumption, and service provisioning

  • Easily deploy in rugged outdoor environments with a temperature range from –40°C to 55°C including high humidity; the sealed cabinets meet IP55 protection ratings, allowing for installation in adverse conditions such as close to salt water, near or in factories
  • Supports remote monitoring and alarms for simple Operations and Maintenance (O&M).Monitors environmental and power parameters
  • SmartAX F series cabinets reduce power consumption and noise with advanced heat dissipation system
  • Integrated structural design ensures rapid onsite installation and service provisioning. The cabinet contains the service device, power supply system, temperature control module, and cable distribution module
Detailed Images

  F01S100





  F01S100







F01S200









F01S200





Specifications

Specifications

Specifications

F01C50

F01E50

F01E100E

F01E200E

F01S50

Dimensions (H x W x D)

600 mm x 550 mm x 160 mm

860 mm x 600 mm x 180 mm

950 mm x 550 mm x 330 mm

1,000 mm x 650 mm x 550 mm

850 mm x 560 mm x 200 mm

Devices

1 x MA5620

1 x MA5626

1 x MA5623

1 x MA5612

1 x MA5616

1 x MA5616

3 x MA5616

1 x MA5612

1 x MA5622A

1 x MA5623

1 x MA5623A

Service Capacity

< 48 lines

< 128 lines

< 128 lines

< 384 lines

< 48 lines

Installation Scenarios

Corridor and indoor

Corridor, basement, and indoor

Outdoor

Outdoor

Outdoor

Installation Modes

Pole-mounted or wall-mounted

Pole-mounted, wall-mounted, and base-installed

Pole-mounted, wall-mounted, and base-installed

Pole-mounted, wall-mounted, and base-installed

Pole-mounted, wall-mounted, and base-installed

Operating Environment

–25°C to +45°C

–25°C to +45°C

–33°C to +45°C

(1,120W/m² solar radiation)

–33°C to +45°C

(1,120W/m² solar radiation)

–33°C to +45°C

(1,120W/m² solar radiation)

Water-proof and Dust-proof Rating

IP31

IP31

IP55

IP55

IP55

Noise Rating

Class4.1 protected-area level

Class4.1E protected-area level

Class4.1E protected-area level

Class4.1E country level

Class4.1 protected-area level

Weight

15.7 kg

49 kg

50 kg

80 kg

46 kg



Specifications

F01S100

F01S200

F01S300

F01D500

Dimensions (H x W x D)

830 mm x 670 mm x 250 mm

850 mm x 750 mm x 350 mm

1,350 mm x 850 mm x 450 mm

1,650 mm x 1,550 mm x 550 mm

Devices

1 x MA5616

1 x MA5616

3 x MA5616/1 x MA5603T

1 x MA5600T

Service Capacity

< 128 lines

< 192 lines

< 384 lines

< 1,024 lines

Installation Scenarios

Outdoor

Outdoor

Outdoor

Outdoor

Installation Modes

Pole-mounted, wall-mounted, and base-installed

Pole-mounted, wall-mounted, and base-installed

Base-installed

Base-installed

Operating Environment

–33°C to +45°C

(1,120W/m² solar radiation)

–33°C to +45°C (1,120W/m² solar radiation)

–33°C to +45°C (1,120W/m² solar radiation)

–40°C to +45°C

(1,120W/m² solar radiation)

Water-proof and Dust-proof Rating

IP55

IP55

IP55

IP55

Noise Rating

Class4.1 protected-area level

Class4.1E protected-area level

Class4.1E protected-area level

Class 4.1E city level

Weight

58 kg

85 kg

270 kg

417 kg
