Geomembrane Welding Machine/welding Machine /sewing Machine From China

Geomembrane Welding Machine/welding Machine /sewing Machine From China photo-1
US$ 900 - 3,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Model Number:
001
Voltage:
110-300v
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shandong, China
Model Number 001
Voltage 110-300v
Power 1800w, 1800W,220V,50HZ
Frequency 50HZ
Weight 13KG
Usage For Geomembrane welding

Specifications

welding machine:
1.Modle: TSD-900
2.Power: 1800W,220V,50HZ
3.Weldable Thick:0.8-3mm
4.Interior Cavity 16mm

 geomembrane welding machine

Product description:



The control of this series of welding machine adopts PID automatic thermostatic control with high control accuracy and low temperature fluctuation; speed control adopts PWM automatic voltage and speed regulation circuit, driven by DC servo motor, with great output torque and the operating is stable. It can maintain a constant speed on the condition of creeping, vertical creeping and variable road load. Also this series of welding machine is stable in performance despite of external temperature and voltage variation.

It can weld geomembrane of various thickness and are applicable for welding of all thermal-fused material such as LDPE, PVC, HDPE, EVA, PP and the like.


This series of welding machine is excellent in performance and easy for operating, with high welding speed and good work quality. It is extensively used in engineering projects such as expressways, tunnels, reservoirs, waterproof of construction and so on



Voltage (V): 220V
Frequency (Hz): 50Hz
Power (P): 1800W
Welding speed (V): 0.5-5m/min
Heating temperature (T): 0-450
°C
Thickness of material to be welded: 1mm-3mm
Overlap width: 120mm
Welding width: 14mm×2, interior cavity 16mm
Seam strength: ≥85% base material (tensile resistant in shear direction), complete machine
Weight: 13Kg
