64-channel ADSL2+ service board over POTS used for huawe dslam ma5600/ma5603ADSL2+ over POTS service board
Built-in SPL
64-channel ADSL2+ service board over POTS used for huawe dslam ma5600/ma5603
ADEE Board
This topic describes the function, working principles, front panel, and pin assignments of the ADEE board, and provides the specifications of the board.
Overview
The ADEE board is a 64-channel ADSL2+ service board. It supports ADSL2+ over POTS, when working a built-in splitter.
The ADEE board can be installed in slots 0-6 and 9-15 of the MA5600 service shelf, and slots 0-6 of the MA5603.
Front Panel :
Front panel of the ADEE board :
|
|||
RUN: running status LED | |||
Green: on for 1s and off for 1s repeatedly |
The board works in the normal state. |
||
Green: on for 0.25s and off for 0.25s repeatedly |
The board is starting up. |
||
ALM: alarm LED | |||
Red: off |
The board works in the normal state. |
||
Red: on |
The board is faulty. |
||
Specifications of the ADEE board
Board |
Dimensions (W x D x H) |
|---|---|
ADEE |
25.4 mm x 372 mm x 399.5 mm |
Pictures:
if you want know more details of the board,you can feel free to contact me:
Skype:jeff.jiang
phone:+86 1364933146
