11KV 33KV 36KV Indoor or Outdoor High Voltage Vacuum Circuit Breaker Quality Choice
US$ 110 - 130
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
hossin
Model Number:
11KV 33KV 36KV Indoor or outdoor High voltage Vacuum Circuit Breaker
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CKG4 CKG3 CKG4-12KV CKG3-7.2KV HV Vacuum ContactorUS$ 300 - 400MOQ: 1 Piece -
CKJ5 CKJ5-1.14KV CKJ5-1140V Low-voltage Vacuum ContactorUS$ 5 - 10MOQ: 1 Piece
-
20KV 24KV Vacuum Circuit Breaker 20 kV 24kV Side-mounted Vacuum Circuit BreakerUS$ 840 - 1,300MOQ: 1 Piece
-
Vs1 Vd4 Vep 11kv 12kv 20kv 24kv Side-mounted Vacuum Circuit Breaker VCBUS$ 840 - 1,300MOQ: 1 Piece
-
Vacuum Circuit Breaker Price ZN63A-12 High-voltage Vacuum Circuit Breaker/VCBUS$ 840 - 1,300MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
hossin
Model Number
11KV 33KV 36KV Indoor or outdoor High voltage Vacuum Circuit Breaker
Type
High Voltage
Poles Number
3
11KV 33KV 36KV Indoor or outdoor High voltage Vacuum Circuit Breaker
Specification
NO |
Item |
Units |
parameters |
1 |
Rated voltage |
KV |
12 |
2 |
Rated Frequency |
HZ |
50 |
3 |
Rated Current |
A |
630.1250.1600.2000.3150 |
4 |
Rated short-circuit breaking current |
KA |
20 25 31.5 |
5 |
Rated short-circuit closing current (peak) |
KA |
50 63 80 |
6 |
Rated short-circuit duration |
S |
4 |
7 |
Rated short-circuit breaking current breaking number |
nos |
50s |
8 |
Rated operating sequence |
|
0-0.3s-CO-180s-CO |
9 |
Rated lightning impulse withstand voltage |
kv |
125 |
10 |
1min power frequency withstand voltage |
KV |
65 |
11 |
Closing time |
ms |
≤ 70 |
12 |
opening time |
ms |
≤ 50 |
13 |
Mechanical life |
Times |
20000 |
14 |
Rated Storage and operation voltage |
V |
AC DC 220/110 |
