Bench and Rotary Sealing Machine for Lunch Box

Bench and Rotary Sealing Machine for Lunch Box thumbnail-1
Bench and Rotary Sealing Machine for Lunch Box thumbnail-2
Bench and Rotary Sealing Machine for Lunch Box thumbnail-3
Bench and Rotary Sealing Machine for Lunch Box thumbnail-4
Bench and Rotary Sealing Machine for Lunch Box thumbnail-5
Bench and Rotary Sealing Machine for Lunch Box thumbnail-6
Bench and Rotary Sealing Machine for Lunch Box photo-1
Bench and Rotary Sealing Machine for Lunch Box photo-2
Bench and Rotary Sealing Machine for Lunch Box photo-3
Bench and Rotary Sealing Machine for Lunch Box photo-4
Bench and Rotary Sealing Machine for Lunch Box photo-5
Bench and Rotary Sealing Machine for Lunch Box photo-6
US$ 2,500 - 20,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Material:
Plastic
Plastic Type:
PA
Industrial Use:
Food
Contact Supplier Request Quote Chat Now
Seal Pack Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Taiwan
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Plastic
Plastic Type PA
Industrial Use Food
Use Other, Sandwich
Feature Disposable
Printing Handling Glossy Lamination
Custom Order Accept
Place of Origin Taiwan, China
Brand Name SEAL PACK TECHNOLOGY .,CO.LTD
Model Number SP-7 & SP-2 Series

Specifications

Bench and Rotary Sealing machine for Lunch Box

Benh and Rotary Sealing machine for Lunch Box



Following information is for In line Type and Rotary Type machine.

Bench type machie please contact us for more detail information.



Product Description



Productivity

2,400~24,000 pcs per hours(depends on number of Molds )
Product Water/Juice/Yogurt/Sauce/Mayonnaise/Jelly/Jam/Powder
Cup Diameter Depends on Customer's choice
Cup Volume Depends on Customer's choice
Sealing Film Material

Plastic Film in Roll with pattern/company name & logo
Power Supply Depends on the power you use
Container Material

PP/PE/PET

Polypropylene, PP (100~140℃)

High Density Polyethylene, HDPE (90~110℃)

Polystyrene, PS (70~90℃)

PET(60~85℃)

PVC (60~80℃)
Bottom Moulds Anodized Aluminum Alloy
Air Consumption  280 Liter/ min
Machine Dimension 3000 x 1000 x 1800 mm (L x W x H)
Control Panel

A Type

  • Traditional Switches and Buttons for simple operation

B Type

  • Equipped with (HMI-Touch Screen), Brand: CONCH, Taiwanese brand

Common Part

  • Variable speed adjustment via speed controller arrange with inverter
  • Additional emergency stop switch for safety protection
  • Equipped with a three-color warning light, it gives a clear warning in case of malfunction of electric control or pneumatic system
Automatic Filling System
  • Ball valve: can be adjusted individual manually
  • Butterfly valve: can be adjusted individual manually
  • Piston device: can be adjusted together/individual manually
  • Re-feeding pipe arrange with one-way valve for connect with the re-feeding pipe (This device should be prepared by piping manufacturer)
  • Liquid level control refill system (Customer should provide refill pump)
Sealing Film & Sealing System
  • Plastic Reel Film Storage Device
  • Photocell Sensor for Film Pattern Mark
  • Waste Film Automatic Collecting Device
Storage Tank
  • Depends on Filling volume and  Productivity
  • jacketed hopper (with thermal keeping material)
  • jacketed hopper (arrange with hot-water recycling device)
Automatic Sealing System
  • Stainless knives
  • Film sensor for detect the film when it ran out, the machine will stop automatically
  • Protect cover is available
  • Independent temperature controller for each mold
    • In case of malfunction occurs in heating system, the indication lamp lights up individually, permitting operator to fast find the problem heating system
  • Automatic Pressing System
    • Pressing the film after heat sealing let the film sealed tighter with cup
  • Heating Sealer
    • Independent temperature controller for each sealing mold
    • Automatic Correcting Film Pattern Mark System
    • Collocating with a photocell sensor of film pattern mark
Automatic Film Cutting System
  • Molding Cutter
  • After cutting for the film, there will be 1.5~2.0 mm left film outside of the cups
Automatic Out-Feeding System
  • Mechanical Cam Type
  • Vancume sucker out feeding system
  • Drop-Down Type
Automatic Dropping Cup System
  • Cup should meet the cup falling condition
  • Sucking rubber device for falling cups is available
  • No Cup No Filling Design
  • Fitted with Cup sensors after cup dropping system
  • Once the bottom mold lacks cup, machine stopped automatic and re-feed cup manually
Machine Frame

Stainless Steel in accordance with sanitation standard / Aluminum Extrusion

Driving Gear and Chain Made by Stainless Steel (SUS#304)
Springs and Screws Made by Stainless Steel (SUS#304)
Driving Gear and Chain Made by Stainless Steel (SUS#304)
Pneumatic Parts ISO applied
Others
  • Inverter: TECO, Taiwanese brand
  • Roller Gear Cam Unit: TAN TZU, Taiwanese brand
  • Solid State Relay: wired connection with temperature for protection, CONCH, Taiwanese brand
    • Locating and positioning accurate with stable
  • Temperature Controller: CONCH, Taiwanese brand
    • Independent temperature controller for each mold
    • In case of malfunction occurs in heating system, the indication lamp lights up individually, permitting operator to fast find the problem heating system





Optional Devices

For Inline Type

Empty Cup De-Dust Vacuum System
  • 2 HP Blower
  • Vacuum system: precision filtration system
  • 1st Filter: Filtrate precision scale_0.5μ;  Winding capacity: 1,641L/min
  • 2nd Filter: Filtrate precision scale_0.01μ; Winding capacity: 1,217L/min
  • Note: Above filtration system has maximum 0.5 inch diameter of inlet and outlet
  • Maximum pressure: 21Bar
  • Temperature withstand up to 79℃
  • Seal up material: BUNA-N-VIYON
  • Body material: SS#304 stainless steel
  • Air compressor cylinder
  • Dust Vacuum Capacity of Empty Cup
  • Capacity: 4800 pcs/hour, 4 pcs/row*20 cycles/min*60 min
  • Transparent Tape (non-wet & non-sticky): Length 5 mm x Width 5 mm x 3 pcs (max)
  • Paper: Length 5 mm x Width 5 mm x 3 pcs (max)
  • Hair: under non-electromagnetic of empty cup, hair length below 50 mm x 5 pcs
  • PP plastic particles: 5 mm3 x 3 pcs (max)
  • Dust (few)

Film UV Sterilizer
  • UV Lamps: Made In USA
  • Sterilization Dosage Reaches : 30,000uw.sec/cm2
  • UV Lamps: PCS High Efficiency
  • Sterilization Rate of E. coli: 99.99%
  • Sterilization Rate of Staphylococcus Aureus: 99.99%
  • Sterilization Rate of Pseudomonas aeruginosa: 99.99%
  • No Contamination, No Residues, No Radiation
  • UV lights guaranteed 9,000 hours of continuous use
  • The housing cover is made of stainless steel
  • The device has the UV abnormal warning alarm
Automatic Clean In Place (CIP) Self-CIP system
  • All the pipe and tank which made by stainless steel SUS#304
  • Includes a 100 liter hopper for recycling cleaning liquid
  • Includes 1 set of recycle pump (1HP)
  • Includes a spurt ball for cleaning in hopper
  • Buyer needs to prepare the CIP liquid

 Date Coding Device
  • Printing Heads: pcs
  • Carbon Ribbon
  • Hot heating the carbon ribbon for printing the expiry date/lot number
  • Control Chassis & Frame



Dust Proof around whole machine is available


  • Start from cup falling system, end before sealing system
  • Besides the sealing system will be tempered glass
  • Can be designed under the CE certificated grade

Product Collecting Disc
  • Collecting Table (SUS): Φ1000 mm x H800 mm
  • Frame: aluminum extrusion
  • Metal sheets made by stainless steel
  • Rotating Speed can be adjusted

Inkjet Printer
  • To print the mfg date and lot number on the packaging via ink
  • Brand: DOMINO or LINX, English brand
  • Frame: aluminum extrusion





Packaging & Shipping
Price term FOB Taiwan Port
Payment 50% T/T down payment and 50% T/T before shipment
Shipment 80~90 days after confirm the order, received 50% T/T down payment, and the correct sample cups/plastic film
Factory acceptance test cost It should be shouldered by the buyer
Delivery Date Estimate before confirm order
Ship via SEA SHIPMENT
Packing Export Standard Packing (Fumed Wooden Crate)
Validity 30 days after issuing day
Certifications

Bench and Rotary Sealing machine for Lunch BoxBench and Rotary Sealing machine for Lunch BoxBench and Rotary Sealing machine for Lunch Box

Company Information
Bench and Rotary Sealing machine for Lunch Box About Sealpack Technology

Seal Pack Technology Co., Ltd. is a reputed manufacturer for a variety of automatic filling & sealing packaging machines. For over 30 years, Seal Pack has earned a reputation for supplying packaging machines that fully meet our customer’s requirements.



No matter if your products are solid, liquid or granule, Seal Pack has the machine to meet your packaging requirements. In addition, Seal Pack also offers complete plant equipment.



From project planning to machine running tests at the customer’s work-site, Seal Pack provides a comprehensive experienced technical service. This ensures that Seal Pack machines will give you the high production, secure sealing finish, with ease of operation and a minimum maintenance.



Based on our tradition of continuous research and development, Seal Pack’s machines have designed by our highly experienced staff.Our machines integrate many fine features in their mechanics and control system, to provide a higher standard of running performance



Each machine is carefully inspected and tested for static and dynamic performance to ensure maximum dependability during operation, higher production speeds and more cost effective packaging operations.
