Mattress tape edge sewing machine

Specifications

1.Taiwan lockstitch sewing head
table manual lifting
table size : 1500 * 1950 mm
capacity:15units/hr



ERS-TE01  Mattress sewing tape edge machine

It is same as tape edge machine both in appearance and in application .The main difference between them is that this machine has add the microcomputer controlling system on the base of this machine .It may change walking carriage's turning speed automatically, which make mattress sewing operation more convenient ,fast ,and the finished turn-flange more beautiful.



Model	ERS-TE01
Auto corner declared	No
lifting form of worktable	manual
worktable size	1400*1950mm
Total power	0.75KW
sewing head	Lockstitch
Working angle of the sewing head	35°-55°
Size of the working table top	50-300 mm,150-400 mm,250-500 mm
sewing head	1100~3000/ rpm
treading speed	5.5~16 m/min
Produce efficiency	10~15 pcs/h
