Horizontal carousel sponge slicing cutting machine

Specifications

1.7 mtrs carousel sponge cutting machine
2.can cut 4-5 pcs foam blocks
3.can add vacuum system
4.for mattress,furniture foam

ERS-HC02 Horizontal circle automatic cutting foam sponge machine:

The machine mainly puts many block foam on the worktable cutting slices at the same time, adopt fully automatic digital control, and setting the number as need cutting thickness and foam density by control box. The worktable runs automatically. The turning speed of worktable is adjustable. Continuously cutting ,the production efficiency is very high ( worktable also choose adding to vacuum equipment).



Model	ERS-HC01	ERS- HC02	ERS- HC03
cutting sponge size	L2000*W1500*H1200mm(4pcs)	L2000*W1500*H1200mm(5pcs)	L2000*W1500*H1200mm (8pcs)
cutting sponge thickness	2-150mm	2-150mm	2-150mm
worktable turning speed	0-3.5r/min	0-3.5r/min	0-2.5r/min
worktable diameter	diameter 6m	diameter 7m	diameter 10.5m
blade length	8940mm	10000mm	10240mm
total power	8.12kw	8.92kw	10.52kw
machine external size	L7000*W6500*H2500mm	L7500*W7000*H2500mm	L11500*W11000*H2500mm
