Help CenterAcrylic Bathtub Forming Machine, Bathtub Vacuum Forming Machine
Related Products
-
FJL-660PC PP/PS Plastic Sheet ExtruderUS$ 24,000 - 26,000MOQ: 1 Set -
FJL-660PC 110 Single Layer Plastic Sheet ExtruderNegotiableMOQ: 1 Set
-
Fjl EPS Foam Sheet ExtruderNegotiableMOQ: 1 Set
-
FJL-660PC-B-IV Three Layer Plastic Sheet ExtruderUS$ 65,000 - 70,000MOQ: 1 Set
-
FJL-WJJ Stationery Plastic Sheet ExtruderUS$ 40,000 - 43,000MOQ: 1 Set
Working Cycle:
Carry materials by hand → clamp the materials → oven move along to forming area → heating → oven move back to heating area →lower-mold up → forming globularity by air pressure(blown) → vacuum(With plug assistant) → cooling → automatic degassing →mold ejecting → lower mold down→ take out the finished product by hand.
Basic units:
- 1. Heater adopts ceramic heating bricks.
- 2. Heater drives by cylinder to insure heater work fleetly and placidly.
- 3. The equipment with the safety and protection equipment.
- 4. Clamp unit, controlled by pneumatic solenoid valve. Clamping unit assembled synchronous unit for material pressing. This machine adopts iron clamp bracket, which can bear high temperature, avoid the clamp bracket metamorphosed and adjust width and length arbitrarily.
- 5. Complete vacuum system includes vacuum room, vacuum pump, vacuum storage gas pot, vacuum pipeline, adjustable air cleaner device and vacuum controlling unit.
- 6. Cooling system assemble air blower and spray gun. The spray gun could be adjusted according to different products making.
- 7. This machine controlled by PLC, panel control system and display and controls all the operation of equipment.
- 8. Automatic degassing before mold ejecting.
- 9. The front door is movable door; it’s convenient for changing mould.
Excellence of equipment:
1. Heater (controlled separately)
A. Heater separately: Set different temperature according material forming demand to insure product quality. Adjusted the voltage of heater by AC voltage meter which can insures the heater temperature steady and save power.
B. Change the heater units fleetly. And it is economical for maintain because it only need change part units.
- 2. Controlling the heater unit separately can short the heating time and economize energy and improve product quality and reduce cost.
3. Adjustable frame: The side size clamping is 20--50mm which can economize the material. And the total of economized material is a considerable amount.
4. Sheet sag control device: Prevented sheet sag after heating by pressure support system, and assembled photoelectric switch.
- 5. The machine with double heaters, forming by vacuum and drove by pneumatic pressure system, It is Suitable for forming ABS, PMMA/ABS, PMMA, PS, HIPS, PE, PP, PVC, PET plastic sheet which thickness within 8 mm.
- 6. Max. Height of Mold can up to 650mm.
