Help CenterHi-speed Automatic Vacuum Forming Machine Thermoforming
Related Products
-
2014 Hi-speed Best Quality Plastic Fast-food Boxes Vacuum Forming MachineUS$ 24,000 - 24,300MOQ: 1 Set -
Hi-speed Plastic Sweets Container Vacuum Forming MachineUS$ 24,000 - 24,300MOQ: 1 Set
-
Hi-speed Disposable Foam Plates Making MachineUS$ 1 - 88,888MOQ: 1 Set
-
2014 Hi-speed Nice Design Vacuum Forming MachineUS$ 1 - 88,888MOQ: 1 Set
-
2014 Disposable Plastic Food Container Making MachineNegotiableMOQ: 1 Set
Specifications
The major electronic devices and pneumatic components are manufactured abroad, which can ensure the stability, safety
parts of the machine
Usage
The FJL-700/1200zk series vacuum forming machine are suitable for processing those reeling sheets including PP. PS. HIPS. PVC. PET etc. under various specifications, it can be used for the forming of disposable fast-food containers, instant noodle bowls, western dinner plates, food coverings (such as sugar boxes, cake boxes and etc), articles of daily use, hardware coverings, children’s toys and trays for raising seedlings of rice, vegetables and other plantations.
Features
This machine adopts advanced PLC controlling system, it can automatically finish a series of tasks including feeding, heating, thermoforming, cooling, drawing off patterns, cutting and stacking.
It’s equipped with a feeding device of a precision electric machine, and geared by a double-lined needle-point chain, this machine can achieve both accuracy and stability during high-speed operations; what is more, it is also easy to make quick adjustments so as to make good use of the plastic sheets to reduce waste.
Equipped with a unique divided temperature control system and a precision remote infrared ceramic heater, this machine can get the most stable and even temperature, and at the same time achieve electricity saving.
This machine also possesses some special features, the switch console can be moved up and down according to needs, it can achieve a delaying vacuum atate or a vacuum atate for a second time, and it can be put on patterns for a second time, also it can draw off patterns through shaking. All these special features can help to accelerate the forming speed and ensure the quality of the products.
The major electronic devices and pneumatic components are manufactured abroad, which can ensure the stability, safety and durability of this machine.
main technical parameters
Model |
FJL-700/1200ZK-A |
FJL-700/1200ZK-B |
Sheet Width |
510-740mm |
|
Sheet Thickness |
0.1-1.2mm |
|
Forming Length |
700-1200mm |
|
Forming Width |
480-700mm |
|
Max.forming Depth |
Negative Mould≤180mm |
Positive Mould≤200mm |
Sheet Material |
PP.PS.HIPS.PET.PVC |
|
Running Speed |
3-12Moulds/Min |
|
Mode of cutting arrangement |
Off Mould |
|
Heater arrangement |
Top Heating With IR Ceramic Heater |
Top+Bottom Heating With IR Ceramic Heater |
Heating Power |
20KW |
35KW |
Vacuum Ration |
100m3/h |
|
Air Consumptions |
1.2m3/h |
|
Water Consumptions |
0.6-0.8m3/h |
|
Dimension |
7.8*1.4*2.2m |
|
Weight(T) |
3 |
3.2 |
Power Supply |
380V/50HZ Three phase four wires |
|
the samples
molds
WOODEN CASE
Warranty and After-sale service
1,The warranty of all our testing machine is one year
2,During this Warranty,it is free to replace the spare parts
3,Out of this warranty, it only charges the cost of the spare parts
4,All our testing machines enjoy a long after-sales service
After all machines are delivered to customer’s factory; Seller should assist buyer to finish preparation work, such as electricity supply, water supply, labors and etc.
Our products are sold in whole China and exported to many countries and regions such as USA, Japan, Canada, Indonesia, Taiwan, Malaysia, Iran, Singapore, Australia, South Africa, Saudi Aribian, Egypt, Turkey, Philipines, etc. Our company slogan is “Credit by Quality, Market by Service”.
We are appreciated with advance equipment, experience and production power. We provide on time after- sales service. We integrate the design, development, production, sales and after-sales services to our clients.
WE have the specification of every machine.
Thanks for visiting our website , need more details welcome to contact me any time !
contact person: Sherry chen Tel:008618358758582
skype: fuxinlong02
