Help CenterFJL-750 Disposable Glass Machine Price, Plastic Disposal Glass Making Machine
Related Products
-
Automatic Plastic Cup Thermoforming MachineUS$ 32,000 - 35,000MOQ: 1 Unit -
SZ-680 Plastic Cup Making MachineUS$ 28,000 - 35,000MOQ: 1 Set
-
SZ-680 Automatic Disposable Plastic Cup Making MachineUS$ 1 - 34,000MOQ: 1 Set
-
SZ-750 II Plastic Cup Thermoforming MachineNegotiableMOQ: 1 Set
-
FJL-660SB-C Fuxinong Plastic Cup Making MachineNegotiableMOQ: 1 Set
disposable glass machine price, glass making machine
making machine glass, glass cup making machine
I. Main Features:
1)It is mainly used to produce different plastic cups, such as ice cream cups, cold/hot drinking cups, yoghurt cups, jelly cups, coffee cup, etc. It could also make some regular shape products, such as bowls, dishes, trays, covers/lids, etc with different moulds.
2) The sheet is driven by pin chain and the pin chain is driven by servomotor. The feeding length could be adjusted by parameter setting through touch screen.
3) The stretching of plug inside of up mould is controlled by servomotor.
4) Mould adopts four pillars to fix the mould.
5 It adopts hydraulic system to drive the movement of the mould.
6) Fill oil automatically to lubricate mechanism movement at certain time.
7) Temperature controller modules to control up and down temperature area.
8) It can finish production at one time through sheet feeding, heating, stretching, forming and in-mould cutting.
9) Stable operation and reliable performance, low noise, high quality.
10) Machine frame adopts square bar to make it. Its lifespan will be longer.
11) The movement of heating oven is controlled by touch screen.
12) Waste sheet winder to collect the waste sheet.
13) Machine frame adpots square steel, machine will more stronger and stable.
14) Its forming sheets as PP, PVC, PS, and PET and other sheet.
Samples of products:
II. Main Technical Parameter:
Model |
FJL-SZ-680 II |
FJL-SZ-750 II |
Max. Forming Area |
650*320mm |
650*420mm |
Running Speed |
15-30cycles/min(According to sheet thickness, material used and product shape) |
|
Running Pattern |
Hydraulic/cam |
Hydraulic |
Oil Pump Motor Power |
7.5KW(Double Pump) |
15KW(Double Pump) |
Cutting Pattern |
In mould automatic |
|
Sheet Material |
PP.PS.HIPS.PET.PVC |
|
Sheet Thickness Range |
0.2-2mm |
|
Max. forming Depth, Sample Height |
120mm |
|
Max. Sheet Roll Dia |
800mm |
|
Heater arrangement |
(120Pieces,650W) Top + Bottom Heating With IR Ceramic Heater |
(152Pieces,650W) Top + Bottom Heating With IR Ceramic Heater |
|
Temperature Controller & Thermocouple |
PID K-Type |
|
Electrical Consumption |
45KW/h |
55KW/h |
Overall Power |
110KW |
130KW |
Air Consumption |
1.5-1.8m3/min, 0.6-0.8 Mpa |
2-2.5m3/min, 0.6-0.8 Mpa |
Dimension |
3.65*1.73*2.5m |
4*1.59*2.6m |
Weight(T) |
4.5 |
5 |
III. Some Parts of Machine:
Wooden Case
Warranty and After-sale service
The warranty of all our testing machine is one year
During this Warranty,it is free to replace the spare parts
Out of this warranty, it only charges the cost of the spare parts
All our testing machines enjoy a long after-sales service
After all machines are delivered to customer’s factory; Seller should assist buyer to finish preparation work, such as electricity supply, water supply, labors and etc.
Our products are sold in whole China and exported to many countries and regions such as USA, Japan, Canada, Indonesia, Taiwan, Malaysia, Iran, Singapore, Australia, South Africa, Saudi Aribian, Egypt, Turkey, Philipines, etc. Our company slogan is “Credit by Quality, Market by Service”.
Any question contact with me please.
Contact Person: Sherry Chen
Tel/Whatsapp/Viber: 008618358758582
Skype: fuxinlong02
