German Technology Clay Tile Making Vacuum Extruder Machine

Name: German Technology Clay Tile Making Vacuum Extruder Machine
Brand: brictec
SKU: 101580731

US$ 10,000 - 100,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Tile Forming Machine

Tile Type:

Ceramic

Xian Brictec Engineering Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Foshan/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Tile Forming Machine

Tile Type Ceramic

Use Roof

Production Capacity 6 - 60 (tons / hr) Adjustable

Place of Origin Guangdong, China

Brand Name brictec

Model Number TL-CXJ-GIICZ56-40

Power(W) (Mixing/Extruding/Vacuum Pump) (30+4X2) /(75-110) (kw)

Dimension(L*W*H) 4,300x2,240x4,030 (mm)

Weight 15000 (kg)

Certification ISO9001, CE

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Tile macking machine

Type TL-CXJ-B40-30, C45-35

l Leading technology specially made for high-grade extruded wet-forming ceramic tiles and bricks,

especially for making the split tiles, roofing tiles, special shaped tiles and clay bricks etc.

l Casting-steel-structured machine body, high strength gear-box, special alloy steel augers etc., to ensure

high quality and reliable of production.(Optional according to the requirement)

Description	B40-30 Parameters	C45-35 Parameters
Dimension LxWx H	4,600x1,800x1,300 (mm)	5,800x1,550x1,450 (mm)
Production Capacity	5 - 8 (tons / hr) Adjustable	8 - 11 (tons / hr) Adjustable
Degree of Vacuum	≤ - 0.092 (MPa)	≤ - 0.092 (MPa)
Augers Nominal Diameter	400 / 300 (mm)	450 / 350 (mm)
Extruding Pressure	3.0 (MPa)	3.0 (MPa)
Mixing/Extruding Motor Power	45 / 5.5 (kw)	55 / 7.5 (kw)
Weight	≈ 6000 (kg)	≈ 11000 (kg)
