Cement rotary kiln is the main euipment for sintering cement clinker.
The cement rotary kiln produced by our company can be used for chemical industry and etc. Through technical renovations, the rotary kiln sintering system made by our company has adopted high measuring precession plunger pump,variable speed adjusted valve,stainless steel spring sheet seal and other national advanced technologies. In order to raise up automation degree, industrial TV has been used at the ki ln head for monitoring of kiln,analog fluorescent screen has been used for display of process flow; infrared scanning system has been adopted for sinterinng zone to directly in vision, convienent on the computer . with the use of these new technologies, it is directly in vision , convienent in operation and reliable in use. Therefore ,the rmalcondition can be raised. Compared to been raised 3-5% up , production has been increased 5-10% and heat consumption has been reduced 15% down
Specification
Spec.(m) |
Capacity (t/d) |
Slope of the kiln shell % |
NO of support |
Rotating speed of kiln (r/min) |
Type of thrust roller |
Main motor |
Main reducer |
weight (t) |
|
Type |
Power KW |
||||||||
Φ2.8/2.5×44 |
300 |
3.5 |
3 |
0.445~2.22 |
Mechanical |
ZSN4-225-21 |
55 |
ZS145-1-I |
177 |
Φ3.2×52 |
600 |
3.5 |
3 |
0.676~3.38 |
Mechanical Hydraulic |
Z2-101 |
100 |
ZS145 |
213 |
Φ3×48 |
700 |
3.5 |
3 |
0.676~3.38 |
Mechanical Hydraulic |
Z2-101 |
100 |
ZS145 |
213 |
Φ3.2×50 |
1000 |
3.5 |
3 |
0.36~3.57 |
Hydraulic |
ZSN4-280-091B |
160 |
ZSY450-40-V |
280.6 |
Φ3.3×50 |
1200 |
4 |
3 |
0.36~3.57 |
Hydraulic |
ZSN4-280-091B |
160 |
ZSY450-40-V |
317 |
Φ3.5×54 |
1500~1800 |
4 |
3 |
0.39~3.9 |
Hydraulic |
ZSN4-315-092 |
220 |
NZS995-28VIBL |
341 |
Φ4×60 |
2500 |
4 |
3 |
0.41~4.07 |
Hydraulic |
ZSN4-355-092 |
315 |
YNS1110-22.4VBR |
434 |
Φ4.2×60 |
3000 |
3.5 |
3 |
0.4~4 |
Hydraulic |
ZSN4-355-12 |
400 |
YNS1400-31.5VBR |
532 |
Φ4.3×64 |
3500 |
4 |
3 |
0.4~4 |
Hydraulic |
ZSN4-355-12 |
400 |
YNS1400-31.5L |
562 |
Φ4.3×66 |
3200 |
4 |
3 |
0.4~3.99 |
Hydraulic |
ZSN4-355-12 |
420 |
ZSY710-35.5-I |
599 |
Φ4.8×72 |
5350 |
3.5 |
3 |
0.36~4.56 |
Hydraulic |
ZSN4-450-092 |
710 |
JH800C-SW306-28 |
854 |
Φ4.8×74 |
5000 |
4 |
3 |
0.35~4 |
Hydraulic |
ZSN4-450-092LP44 |
630 |
JH710C-SW305-40 |
854 |
Φ5×74 |
6000 |
4 |
3 |
0.35~4 |
Hydraulic |
ZSN4-450-092 |
710 |
JH800C-28 |
894 |
Φ5.2×78 |
6000 |
4 |
3 |
0.4~4 |
Hydraulic |
ZSN4-450-12 |
800 |
JH900C-SW305-28 |
990 |
Φ5.6×87 |
8000 |
4 |
3 |
Max4.23 |
Hydraulic |
ZSN4-450-12 |
800 |
JH900C-SW305-25 |
1201 |
Φ6×95 |
10000 |
4 |
3 |
Max5 |
Hydraulic |
ZSN4-500-092 |
950×2 |
JH900C-SW305-28 |
1580 |
