Solar PV Ground Mounting Structure G1-312-P3

Name: Solar PV Ground Mounting Structure G1-312-P3
Brand: Intelliware
SKU: 101569223

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Intelliware

Model Number:

G1-312-P3

Kept Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Intelliware

Model Number G1-312-P3

Specification Normal

Application Industrial

Solar Power (W) 8.3kw

Specifications

G1-312-P3 is ground solar mounting structure with benefit of limited installation time, Economic system, long working life.

Open Ground Solar Mounting Structure: Model G1-312-P3

A economic system flexible installation for 36 panel (8.3kw system), suitable installation in inland without heavy wind.

Feature:
*	Stable and trustable structure according to DIN1055 for any kind of weather situation.
*	Any kind of Alu Framed Solar Panel in any number of rows and columns on the table.
*	Angle fixed or Manu Adjustable during season changing are all available.
*	Warranty 10 years durability on materials and working life more than 25 years.

Product Benefit:
Stable and Durable
Because a concrete foundation is used, the pre-fabricated concrete components will
give the structure a strong & durable base. The concrete foundation is very easy to built
and can be used at any kind of soil situation.
Standard Technical Data:
Design Standard:		EUROPE: DIN1055-2005 / AMERICA: ASCE 7-2010
Main Post:	S235 Structure steel made square tube or SCH40 round tube with heavy duty hot dip galvanized.
Main Rafter:	S235 Structure steel square tube or C type profile steel with heavy duty hot dip galvanized.
X support:	S235 structure steel flat C type profile steel with hot dip galvanized.
Beam:	Aluminum Profile 6063-T5 / 6005-T6 with anodic oxidation treatment
Clamp:	Aluminum clamp 6063-T5.
Fastener:	High grade steel bolt and nut with 3 layer dacromet coating.
Foundation:	Pre-casted concrete foundation with embedded fasteners.

Principle:	Pre-welding and some accessoreis already assembled on structure to save the time of installation.
Weather Class for different surrounding:
