Description of Calibration Machine:
This equipment is suitable for surface thickness gauging and processing of man-made stone, granite and quartz stone slabs. High-speed rotation diamond rollers are adopted to carry out the rigidity milling and scraping on the slab surface, which gives the slab a smooth surface and unitary thickness. Accordingly, it helps to increase the grinding output and quality as well as the processing cost.
Performance & Advantage:
- There are 4-8 sets of swaying diamond disc thickness fixed heads for a standard model machine.
- It is installed with new technology and High energy saving grinding head assembly.
- Each calibrating heads are installed in the middle of the beam, it over come the defect of incline problem of the tradition model.
- Each disc calibrating head adopts cylindrical sliding sleeve for up and down moving separately. There is empty middle of the main axis for water cooling.
- Disc calibrating heads adopt swaying bearing, gear casing and frequency control for speed.
- Main transmission adopts cycloidal-pin reducer, frequency control for speed.
- The conveying belt adopts quality PVC flat belt.
Configuration &Technical Parameters:
Model |
KSYD 1650/4-8 |
Production Capacity |
0.6~1 m/min |
Brand Name |
Foshan KingSun |
Weight |
9~18 T |
Power |
96.88~186.36KW |
Voltage |
380~450V |
Specification |
6900~10100 X3500 X 2200mm |
Packing |
Nude packing |
Port of loading |
Foshan |
Guarantee |
One year(for non-human factor malfunction) |
MOQ |
One set |
Why to choose us?
- Warranty date:one year, MOQ:one set
- Fast delivery and good service
- All of our products have been strictly before shipment
- Customers satisfying customers forever
Turnkey Projects:
- Complete project configuration and layout suggestion on turnkey basis.
- Machineries manufacturing and detail drawing of foundation for plant.
- Installation commissioning and training for operators, production and technology.
- Project consulting services.
Packaging & Shipping:
About our company:
Cooperative client:
Welcome to visit our factory at any time!
