Home > Electrical & Electronics > Inverter > Power Inverter > High Quality Frequency Inverter Wosn Frequency Inverter 60hz/50hz

High Quality Frequency Inverter Wosn Frequency Inverter 60hz/50hz

Name: High Quality Frequency Inverter Wosn Frequency Inverter 60hz/50hz
Brand: wosn
SKU: 101565859
Availability: InStock

High Quality Frequency Inverter Wosn Frequency Inverter 60hz/50hz thumbnail-1

High Quality Frequency Inverter Wosn Frequency Inverter 60hz/50hz photo-1

US$ 99 - 1,000 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

wosn

Model Number:

SV8-2S

Contact Supplier Request Quote Chat Now

Wenzhou Wosn Electron Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

BINGBO/SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name wosn

Model Number SV8-2S

Output Power 201 - 400KW

Output Type Triple

Weight 3KG

Input Voltage Single-phase 220V, three-phase 220V,three-phase 380V

Output Voltage 2-200/220V /380V

Type DC/AC Inverters

Output Frequency 0-500Hz

Output Current 0-600amp

Specifications

1.AC variable speed drives
2.Unique design,advanced technology
3.Absolutely reasonable price
4..Energy Saver

Product Description

SV8-2S Mini Sensorless Single Phase Frequency Inverter is using high performance digital signal processor and optimizing control algorithm, provides fans and pumps etc with high speed ,flexible, safety control

1.High-performance non-inductive vector control, has the very good low frequency torque

2.Mini design, simplicity of installation , easy to operate, highly reliable.

3.Suitable for all kinds of OEM applications

4.Wide industry application . to expand special function according to different industries.

5.V/F curve &multi-inflection point setting, flexible configuration

6.Have strong ability of overload: 150% rated current 1 minute, 180% rated current for 3 seconds

When communication function: with RS485 standard communication interface, supports both ASCII and RTU format MODBUS communication protocol

Technical Data

Item		Item Description
input	Rated voltage, frequency	Single/Three phase 220VAC, three phase 380VAC, 50/60HZ
input	Allowable voltage range	Voltage fluctuation range:-20% ~+20% Voltage unbalance rate<3% ; frequency fluctuation<±20%
Output	Rated Voltage	Three phase: 0~ input voltage
Output	Frequency	0~400HZ
Overload capacity		Type G: 150% 1 minute , 180% 1 second ; 200% transient protection . Type P: 120% 1 minute , 150% 1 second ; 180% transient protection
Control function	Modulation capacity	Optimal space voltage vector PWM modulation
	Control method	Speed sensorless vector control(SVC)
	Frequency accuracy	Digital setting: Max.frequency x±0.01% Analog setting: Max.frequency x±0.2%
	Frequency resolution	Digital setting :0.01Hz, Analog setting : Max. Frequencyx0.1%
	Starting frequency	0.00~10.00HZ
	Troque lifting	Automatic torque lifting: To lift the torque automatically according to the output current. Hand — operated torque lifting : Range:0.1~30.0%.
	Slip compensation	Setting range: 0~150%. The inverter output frequency can be auto-regulated within this range according to the motor load so as to reduce the speed variation of the motor due to load fluctuation .
	Acceleration/ Deceleration	0.1~3600.0 sec/min, which can be set in sequence.
	Carrier frequency	1.0~15.0KHz
	Jog Function	Jog frequency range:0.01~400.0HZ, Jog acceleration/Deceleration time, 0.1~3600.0 can be set.
	V/F curve	1.linear curve, 2. quadratic curve (conic) 3.User defined V/F curve.
	Automatic energy-saving operation	Auto optimize V/F curve according to load fluctuation to realize energy –saving operation.
	Auto voltage regulation (AVR)	When the network voltage changes, it can regulate PWM output automatically to maintain constant voltage.
	Built –in PID	This can form a convenient closed-loop control system (CLCS), and is applicable to pressure control, flow control and other process control .

Our Services

1.We will ship item to worldwide by DHL, FEDEX,TNT,UPS,EMS,AIR,SEA.

2.Item will be shipped out within 3 business days after cleared payment being received. After we deliver goods, we will give you tracking number.

3.Please leave us your phone number after payment and double check your shipping address,that is very helpful for shipping.

4.In order to ensure you receive you order tax free upon import, we will declare it as a 'GIFT' with a lower value. This lower price does not reflect the total price you paid or the market value of the product and may not apply to countries with different tariff rules. Any import charges or fees are the buyer's responsibility.
