Excellent Solid Control System Sand Pump Manufacturer

US$ 300 - 8,600 MOQ: 1 Set

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

NNT

Model Number:

ZJQ Submesible Sand Pump

Shijiazhuang Nainater Slurry Pump Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

XINGANG

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name NNT

Model Number ZJQ Submesible Sand Pump

Theory Centrifugal Pump

Structure Single-stage Pump

Usage Other

Power Electric

Standard or Nonstandard Standard

Fuel Diesel

Pressure High Pressure

Application Submersible

Specifications

Submersible Sand Slurry Pump
1. Wearable Chromium Alloy Material
2. Machinery sealing device
3. High pumping efficiency

Submersible Sand Slurry Pump

Application:

ZJQ type Submersible Sand Pump is vertically submerged under water and driven by electric.
Suitable for conveying liquid with slurry, solid particles of gravel, cinders, tailings, etc.
Commonly used in river dredging, sand pumping vessel, sewage treatment plants, metallurgical industry, mining, power plants, etc.

Features:

Wear parts are all constructed with abrasion resistant materials - chromium alloy; so pumps have better stability & longer service life.
Unique mechanical seal device can prevent the electric motor from high pressure water and impurities; thus high suction efficiency can be ensured.
In addition to the main impeller, a pair of agitation impeller is equipped to help break and mix the sludge.
Easy installation, operation and cost saving, since no additional vacuum pump or pump house is needed.
Professional technology support is provided during the whole process of the usage and maintenance.

work diagrammatic sketch

Pump Detailed Pictures(with agitator)

Technical Parameter :
