SX3800 ultrasonic flaw detector/ultrasonic test equipment testing
Product Description
The home is in the lead:
1, high speed, the Gao Liang large screen color field sends the demonstration, under the glare normal work
2, an operation fast crack detection, momentarily prompts crack detection help information
3, 5 independent crack detection channel, 500 crack detection data storage
4, the non-memory effect highly effective lithium battery, guarantees continuously 4 hour not power failure work
Specifications:
SX3800 ultrasonic flaw detector/ultrasonic test equipment testing
| Transmitter Pulse | Square Wave Pulser | |||||||||
| Transmitter Pulse Voltage | Transmitter Pulse Voltage: 25 ~ 400V, continuously | |||||||||
| Test Modes | Pulse echo and dual transmission | |||||||||
| Damping | 400, 80 Ohm | |||||||||
| Frequency | 0.5 ~ 20MHz. Broadband / narrowband optional | |||||||||
| Gain | 0.0~ 110.0dB. Steps as 0.1, 1.0, 2.0, 6.0 dB | |||||||||
| Material Velocity | 1000 ~ 15000m/s continuously adjustable. 30 common material velocities selectable | |||||||||
| Range | 0.0~ 6000mm longitudinal wave at steel velocity. Range continuously variable with minimum 0.1mm increments | |||||||||
| Rectification | Positive halfwave, negative halfwave, full wave, RF | |||||||||
| Alarm | Real-time alarm signal indicated by horn or LED indicator | |||||||||
| Display | 5.7" high-brightness TFT color LCD | |||||||||
| Pulse Shift | -20 ~ 3000μs | |||||||||
| Probe Zero Offset | 0 ~ 999.9μs | |||||||||
| Pulse Repetition Frequency (PRF) | 25 ~ 1000Hz, auto and manual adjustment modes optional | |||||||||
| Vertical Linearity Accuracy | ≤3% | |||||||||
| Horizontal Linearity Accuracy | ≤0.1% | |||||||||
| Surplus Sensitivity | ≥60dB (200dia.2 flat bottom hole) | |||||||||
| Resolutions | ≥34dB | |||||||||
| Dynamic Range | ≥30dB | |||||||||
| Reject (suppression) | 0 ~ 90% | |||||||||
| Electric Noise Level | <10% | |||||||||
| Interface | C6 transducer connections, USB HOST, LAN, RF OUT, Two-dimensional encoder interface | |||||||||
| Power Supply | Large-capacity Li Battery, no memory effect; Battery Operating time: More than 6 hours | |||||||||
| Environmental Temperature | -30 ~ 50℃ | |||||||||
| Relative Humidity | 20% ~ 95%RH | |||||||||
| Weight | 1.5Kg (with battery) | |||||||||
Applications:
Widely used in steel, boilers, pressure vessels, aerospace, power, petroleum, chemical, marine, military, petroleum pipeline, ship-manufacturing, automobile, machinery manufacturing, metallurgy, metal processing, steel structure, railway transportation, nuclear power, and relevant departments in colleges and universities.
- Small dimension, lightweight, portable, fully-sealed, highly-reliable design especially suitable for working outdoors.
- Up to 640MHz sampling frequency, measurement resolution of 0.1mm with minimum range of 3mm.
- Operating Frequency: 0.5 – 20MHz, surplus sensitivity up to 65dB.
- Bright, high resolution (640×480) color TFT display realizing the best measurement result in similar products.
- High performance square wave pulser with tuning option allows the operator to tune the pulse width of the square wave pulser to optimize transducer performance.
- This maximizes signal-to-noise and penetration in difficult materials such as highly-attenuated materials or thin work-pieces.
- LAN port allows remote data transfer and management. It provides management to instrument parameters when the instrument is used as independent square wave pulser.
- High-speed USB interface allows data storage on USB drive and PC communication. To interface with a mouse to secure accurate analysis on report with A-scan.
- Internal charger, auto switch between “charge” and “work”. Power supplied by battery or AC mains. The operating time of onboard Li battery is more than 6 hours.
- Multi-software functions to meet all inspection needs, unique keypad organization and rotary knob operation, user-friendly design for menu, English/Chinese
- language menu options, English/Chinese input and edit functions make the inspection much easier.
- Automatically test the transducer frequency, tune the pulse width of square wave pulse to optimize transducer performance.
- Thickness alarm function, continuous storage function of waveform and various measurement modes of waveforms.
- Automatically calibrate instrument specifications and search the peak value.
Advantages:
- Remarkable performance price ratio: 3800S colored digit ultrasonic flaw detector
- the performance is stabler, carries is more relaxed
- the demonstration is clearer, operation simpler
- the superiority two: compare in the volume is big
- the weight heavy table model ultrasonic flaw detector, has the unequalled scene to carry the superiority (complete machine weight 1.5 kilograms)
- superiority three: Gao Liang high resolution colored TFT to demonstrate
- superiority four: highly effective lithium batteries, after ultra long operating time
- superiority five: disposition computer communication card and communication software, (basis customer request), the crack detection data may be directTransmits to the computer printing crack detection report
| Item | Quantity |
| main unit | 1piece |
BNC cable, PC software |
each one |
Straight probe, Angle probe |
each one |
Power adapter |
1piece |
Packing:pack in suitcase and standard export carton
We supply one year warranty and a long-time technology support.
Customer Service
"customer first" aways is our main goal , The technical support department solves all doubts and requirements from users by telephone, Internet, etc. We emphasize on product and service quality.
"Honesty and high quality , customers and service first" is our eternal aim.
1.How to Place an order?
In order to recommend you the most suitable Ultrasonic Flaw Detector and quote you the accurate price, please provide the
information as follows:
1. What forged parts or metal product do you want to detect?
2. How about the product size?
3. What metal is your product made of?
4. Do you have any special requirement for the technical parameters?
5. Which price terms and payment terms could you accept?
6. Please advise which shipping ways you will accept.
7. If you have agent from China, please provide your agent's contact information.
2. How do you ensure the quality of products?
We have a complete quality control system, all of our products were fully inspected by professional QC departments before shipping.
All of our instruments have CE and other important certificates.
