Specifications
1.Impored co2 Metal RF laser tube2 Beam Expander
3.Scanning Mirror
4.Control Card
5.two years warranty
Online flying color laser marking wood craft machine
1. Strong text layout and graphics processing functions can automatically generate lot numbers and serial number.
2. Flexibility to modify software functions, continuously adjustable.
3. Speed, safety and environmental protection marks a clear non-erasable.
4. Flying (on-line) laser marking machine can mark on metal and most of non-metal materials.
5. With red light position device accurately indicates the location of laser head process eliminate the trouble
| Model | BML-CL | BML-DL | BML-FL |
| Laser Power | 30W/55W | 50W 75W 100W | 10W 20W 30W |
| Laser Tube | USA RF Laser Tube | YAG LASER MODEL | Fiber Generator |
| Laser Wave Length | 10640nm | 1064nm | 1064nm |
| Cooling | Air Cooling | Air Cooling | Air Cooling |
| Marking Width | 110mm or 200mm(According to Filed Lens) | ||
| Marking Length | No Limited | ||
| Minimum Line Width | 0.1mm | ||
| Minimum Character | 0.3mm | ||
| Marking Speed | ≤10000mm/s | ||
| Marking Depth | ≤1mm | ||
| Repeatability | ±0.01mm | ||
| Maximum Line Speed | 70m/min | ||
| Flying Marking the Number of Rows | <8 lines | ||
| Character Type | In Chinese and English Characters, Numbers, Symbols | ||
| Power | AC220V±10%,50Hz/15A | ||
| Total Power | |||
| Temperature | 5~40°C | ||
| Total Weight | 220KG(No Conveyor) | ||
Applicable Materials:
Bar code marking packaging industry, packaging industry, plastic bottles, paper, bottle caps, wires, serial number of food, medicine marking.
Sample
Jinan Bodor CNC Machine Co.,Ltd has been always devoting to the research and manufacturing of the CNC products such as Cutting, Engraving and Marking Machines and so on.Today, Bodor CNC has developed to a large worldwide Manufacturing Group, and becomes an excellent leader of the world in this field.Bodor CNC was founded in 2002, and changed its name to "bodor" formly in 2008.We can supply Laser Cutting, Engraving and Marking Machines,Dot Peen Marking Machines, and many other industrial automation equipments.Meanwhile,we can also supply industrial automation sulutions according to your special needs ...
Please tell us what you need:
1. What material do you need to cut/engrave?
2. What is the thickness and size of each materials?
3, What is your business industry? signage or art craft works or what else ?
4, What is your full name,email,company name,website and contact number ?
We are glad to provide custom-made laser solutions and distrbutors wanted all over the world.
