Product Details
Type: | Other, water well drilling rig, Drilling Rig | Power Type: | Diesel | ||
Place of Origin: | Zhejiang, China | Brand Name: | KAISHAN, Kaishan | Model Number: | KW30 |
Usage: | Other, Water Well, Digging Water Wells | Power(W): | 110KW | Dimension(L*W*H): | 5200*2300*3200mm |
Weight: | 9500KG | Certification: | CE,ISO9001,ISO14001,ASME,ENERGY SAVING CERTIFICATE | Warranty: | 24 months after sales service |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
used truck mounted water well drilling rigportable water well drilling rigs for sale
Portable Water Well Drilling Rig for sale /small Crawler Drilling rig machine/ KW30 Water Well Drilling Rig
Specification of KW30 Multi-Function Well Drill Rig | ||
Structure | Parameters | |
Model No | KW30 | |
Dia.of hole | 168-300mm | |
Drilling depth | 300m | |
Working pressure | 1.05-2.46 | |
Air consumption | 16-40m3/min | |
Ground clearance | 280mm | |
Support cylinder stroke | 460mm | |
Feed cylinder stroke | 1750mm | |
Feed power | 50000N | |
Lift power | 150KN | |
Speed of rotator | 69-125rpm | |
Rotation torque | 4800N·M | |
Climb capacity | 25o | |
Traveling speed | 0-2.5km/h | |
Dimensions | 5200×2300×3200mm | |
Weight | 9500KG | |
Engine model | YC6B150Z-T21,Engine | |
Power | 110KW/150HP | |
Rotation speed | 2100rpm | |
1.Impact Hammer | SPM480 | |
2. Dia. Of rod | Φ102mm | |
2.Length of Rod | 3m | |
3. Dia.of Bit | Φ254-300mm | |
Recommend compressor | LGCY-33/25 | |
Air delivery(m³/min) | 33 | |
working pressure(Bar) | 25o | |
diesel engine | cummins,QSZ13-C550,550HP |
KW30 Water Well Drill Rig is a light, efficient and multifunction drilling plants. The power system is provided by the air compressor. It is well received by professionals of drilling well, irrigation well, geothermy well and other well holes, especially for water intake projects in mountain areas and lithostrome. The drill rig can drill holes in various stratum and the diameter of the hole reaches 300mm. It uses the late-model hydraulics, large torque hydraulic motor and cylinder system powered by well-known multi-cylinder engine. Its unique pump package design easy to maintenance and lower cost of upkeep. Its centralized hydraulic control board facilitates operation. The drill rig adopts crawler chassis and cross-country performance is very well.
1.Dual motor rotating mechanism
2.Centralized operating system
3.Double cylinder propulsion system
4.Diesel two filter bodies
5.Safe and stable traveling system
6.Triple pump assemble
1.Outside package:Standard export wooden cases
2.Inner package:Stretch film
1.Our company is located in Beijing and our factory is located in Zhejiang province, which covers an area of 514,800 square meters with a total assets of one billion dollars.There are 6000 staffs including 1075 technicians.
2.We are the largest compressor and the main pneumatic tool manufacturer in China. In 2010 it produced and shipped 27,000 screw compressor units and 200,000 reciprocating compressor units.
3.KAISHAN compressor has a complete vertical integrated production line for compressor from the foundry plant, the airend plant, the pressure vessel plant, the sheet metal plant and the heat exchanger plant to the final unit and system assembly plant.
4.We are over 10 years professional manufacturer of air compressor and drill rig, good quality and competitive price which is guaranteed with CE,ISO9001,ISO14001, ASME, GC energy saving certificate.
Quality Control
1.KAISHAN Group established Development Center in Jersey North America, and the top international compressor expert Dr. Tangyan designed the world-class SKY rotor ."Design in North American, Made in China."
2.Advanced equipment of kaishan screw air compressor
Trade show and customers
Main products
1) Screw Type Air Compressors ( Air delivery:0.8m³/min -72m³/min;Work pressure: 8-13Bar;Power: 7.5Kw-400kw)
2) Diesel Driven Portable Screw Air Compressors (Air delivery:6m³/min-39m³/min ,Work pressure:7-35Bar,diesel engine:58kw-630kw )
3) Motor Powered Portable Screw Air Compressors( 350CFM – 910CFM)
4) Mining Piston air compressor(Air delivery:1.35m³/min -13m³/min;Work pressure:5-7Bar;Power: 11Kw-75kw)
5) Industrial piston air compressor(Air delivery:0.08m³/min -4.8m³/min;Work pressure:8-40Bar;Power: 0.75Kw-75kw)
6) Drill rig (Include Water well drill rig)
7) Rock Drill(YO18-Y19-YT23D-YT24-Y26-YT28)
Certificates
We have special service team which will offers you professional guidance:
1.Low maintenance cost, high efficiency.Minimizing downtime of the equipment.
2.Planned maintenance budget.Maintenance plans are designed according to the customers' different requirements.Providing dedicated and experienced maintenance technicians.
3.Our sales team will response for your question within 24 hours(holidays excluded)
4.Technical support will be available in any time. Providing dedicated and experienced maintenance technicians.
5.Quality Control:
1)We have our own experienced QC
2)There will be strict inspection and testing for every order before shipping out.
6.After-sale Service:
1)Quality Guarantee:12 months from delivery date(quick-wear part except)
2)For warranty repair/ replacement, user should send defective items back then supplier re-supply the same to user within assurance period for free(user in charge of freight fee)
The information you may like to know before order:
1.Payment terms:
T/T 50% in advance ,the balance should be paid within 5days against the B/L date
2.Delivery time:
Within 20 days after receiving your advance payment
3.Shipping way:
Sample order: We suggest courier and express service or by air
Bulk order: We suggest by air or by sea
4.Packaging:
1)Outside package:Standard export wooden cases
2)Inner package:Stretch film
5. HS CODE:
Air compressor:8414809090
Drill rig:8430310000
