JT Double Layer Water Immersion Automatic Used Equipment

Name: JT Double Layer Water Immersion Automatic Used Equipment
Brand: JINTAI
SKU: 101493685
Availability: InStock

JT Double Layer Water Immersion Automatic Used Equipment thumbnail-1

JT Double Layer Water Immersion Automatic Used Equipment photo-1

US$ 15,000 - 70,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

JINTAI

Model Number:

JT-SC

Contact Supplier Request Quote Chat Now

Zhucheng Jintai Food Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name JINTAI

Model Number JT-SC

Condition New

After-sales Service Provided Engineers available to service machinery overseas

double layer suitable meat production water immersion automatic used equipment

Applicable Scope:

1. Plastic container: PP bottle, HDPE bottle

2. Soft package: aluminum foil bag, high temperature cooking bag

3. Gas-packing boxes

Model:

diameter(mm)	length (mm)	volume(m³)	Body Thickness (mm)		water pump
			Body Thickness (mm)		model	quantity
			Sterilizer pot	Hot water pot	model	quantity
φ500	800	0.20	4	4	DN20	2
φ600	1000	0.35	4	4	DN32	2
φ700	1200	0.57	4	4	DN40	2
	1500	0.69	4	4	DN40	2
	1800	0.80	4	4	DN40	2
φ900	1800	1.37	4	4	DN65	2
φ1000	2200	2.03	4	4	DN65	2
	2400	2.18	4	4	DN80	2
	2600	2.34	4	4	DN80	2
	3000	2.66	4	4	DN80	2
φ1200	2700	3.56	5	5	DN80	2
	3000	3.90	5	5	DN80	2
	3600	4.58	5	5	DN100	2
	4000	5.03	5	5	DN100	2
φ1300	3000	4.62	5	5	DN100	2
	4000	5.95	5	5	DN100	2
	5000	7.27	5	5	DN100	2
φ1500	4000	8.04	5	5	DN125	2
	5000	9.80	5	5	DN125	2
	6000	11.58	5	5	DN125	2

Design pressure	0.35 Mpa
Maximum working pressure	0.30 Mpa
The material of pot body	Sus304
Design temperature	147°C

Characteristic
1. Sterilization in short time
Utilize double-tank hot water circulation for sterilization. Heated the water in the hot water tank to the required temperature of sterilization in advance, the sterilization time can be reduced and work efficiency can be improved.
2. Energy effective
The working medium during sterilization is recyclable. It reduces the production cost by saving energy, time, labor and material resources.
3. Even exchange of the water flow, even temperature, no dead area
It utilizes the international advanced technology, hot water circulation and immersion for sterilization. In the process of sterilization, circulation water in the sterilization trough will be uninterruptedly shifted up and down, left and right. It ensures the heat distribution of any spot in the trough is even. It effectively puts an end to the phenomenon of dead area in the process of sterilization and makes the guarantee period of the product more stable and longer. The temperature in the sterilization tank stays stable in all stages of the sterilization, which ensures the qualification rate of F value.
4. Automatic system
The whole sterilization process is controlled by PLC. It is a one-time action without manual operation. It utilizes the chart plate and screen touch control. All time intervals are controlled by the simulate sensor and automatic valve. The digital exhibition of pressure and temperature makes it applicable to input any pre-programmed pressure and temperature models into the computer. The computer can hold 100 sterilizing formulae.
5. Simulate temperature control system where the setting of multi-stage heating system is available.
The sterilizing method by multi-stage heating can minimize the heat on food, which can keep its original flavor, taste, nutrition and color to the utmost and make every kind of food sterilized in its best condition. The accuracy of the sterilizing temperature is up to ±0.3 so as to avoid over boiling or incomplete sterilization.
6. Function of measuring F-value
Every retort produced by Jintai can be equipped with F-value measuring instrument. The F-value software can make the F-value calculation every 3 seconds. All sterilizing data including sterilizing conditions, F-value, time-temperature curve, time-pressure curve and so forth can be saved or printed after the processing of data processing software to serve the production management.
