industrial air high efficiency good quality low price high pressure compressor
Function
The series air compressor widely used in pneumatic lock,pneumatic tool,tire inflation ,blowing process ,spray paint,sand blasting and fluidic element.
Characteristics
1.Strongly power -driven and big airend with design,the air compressor owns bigger and heavier main parts than other products in the same trade with better selection and sufficient using of materials especially with main fittings.In addition, it is more suitable to pe applied in the continuous operation under heavy load for long woring time with higher reliability and longer lifespan.
2.Special designed is made in heat emission and air flow,which leads to low air-output temperature and low possibility of carbon deposit.
3.Composite ring valve is adopted in design.with the valve plate made of stainless steel from Sweden and the spring of valve block made of special spring steel wire from Japan with no bending motion in operation ,the valve processes excellent properly and ideal lifespan index.
4.The piston ring imported from Japan is introduced in designing pistol ring ,which is durable and sealable.
5.Crankshaft undergoes high-frequency hardening,which enables it especially abrasion-proof.
6.Some relevant working units are received precision balance,which makes it more stable with lower noise.
7.Special oil separation construction is built inside the fronted jackets,so no oil vents from the breather valve ,which ensures low oil consumption and deanness of machine body.
8.The core of air filter is made of imported filter paper ,which acts well in filtering and absorbing noise.
9.With rational design in the flaring angle of copper socket pipe and protecting jacket,it avoids cracking and air leaking.
10.Pressure switch ,contactor unit and thermorelay are imported with famous brands as “schneider” to ensure the reliability in control and protection.
11.The are four types available in controlling air flow as automatically air controlled,electric and air controlled (manually switch),and intelligent two-way controlled one,which cater to different demand of customers.
12.If the air delivery condition is complex ,the intelligent controller is recommended to be installed ,which is a device that can switch automatically between two different modes as electric or air controlled when feeling the condition of air delivery.In addition ,it also has memory that can memorize your habits of using air and enter into the corresponding controlling mode.If your habit changes,it will adapt to it .With the help of it,it is electricity-saving,convenient and also prolongs the working lifespan of air compressor.
|
No. |
Model |
Motor power HP/KW |
CYLINDER (DLA×QTY) (V) |
CAPACITY (m³/MIN) |
WORKING PRESSURE (Mpa) |
Air TANK (m³) |
DIMENSIONAL SIZE (L×W×H) |
Weight (kg) |
1 |
KBH-45 |
40/30 |
LP155×2 MP120×1 HP 70×1 |
2.0 |
4.0(40) |
NO |
1650×1250×1150 |
860 |
2 |
KB-45 |
40/30 |
LP155×2 MP120×1 HP 70×1 |
2.2 |
3.0(30) |
NO |
1650×1250×1150 |
860 |
3 |
KBH-35 |
30/22 |
LP155×2 MP120×1 HP70×1 |
1.6 |
4.0(40) |
NO |
1650×1250×1150 |
800 |
4 |
KB-35 |
30/22 |
LP155×2 HP 80×1 |
1.7 |
3.0(30) |
NO |
1650×1250×1150 |
800 |
5 |
KBH-15 |
20/15 |
LP120×2 MP100×1 HP55×1 |
1.2 |
4.0(40) |
0.35 |
1800×730×1330 |
650 |
6 |
KB-15 |
20/15 |
LP120×2 HP65×1 |
1.2 |
3.0(30) |
0.35 |
1800×730×1330 |
600 |
7 |
KBL-15 |
20/15 |
LP120×2 HP80×1 |
1.3 |
2.5(25) |
0.35 |
1800×730×1330 |
600 |
8 |
KB-10 |
15/11 |
LP100×2 HP55×1 |
0.7 |
3.0(30) |
0.28 |
1690×665×1200 |
550 |
9 |
KBL-10 |
15/11 |
LP100×2 HP65×1 |
0.78 |
2.5(25) |
0.28 |
1690×665×1200 |
550 |
