OEM industrial panel pc

Display Feature

Display Screen

17″ TFT LED

Resolution

1024*768

Brightness

350 cd/m2

Contrast ratio

400:1

Touch Screen

Resistive touch screen

Performance

Chipset

Intel ®ATOM D525 + ICH8M

Memory

2G memory (DDRIII), up to 4GB

Hardware Monitor

Monitors voltage, TEMP and CPU fan speed

Watchdog Timer

Programmable 256 levels timer interval, from 1 to 255 sec, setup by software

Storage

HDD:320GB  2.5'HDD

CF :(Optional)

Power Supply

100~240VAC/50~60Hz (Power adapter)

12VDC/5A or 9~36VDC Optional (No power adapter)

Power Dissipation

28W (standby);

40W (Running MaxPower 100%)

O/S

Operating System

Windows XP/ Windows 7/ Linux

I/O Interface

USB

4*USB2.0 Ports

Serial Port

4*RS232 (1~2*RS485 Optional)

Ethernet

2* RTL8111DL 10/100/1000Mbps  RJ45

Audio

1*Line out

Display

1*VGA

Environmental

Anti-vibration

5-19Hz/1.0mm amplitude;19-200Hz/1.0g, acceleration

Anti-shock

10g acceleration, 11ms duration

IP Level

Front panel IP65(Optional)

Reliability

MTBF≥50000h; MTTR≤0.5h

Operating Temperature

-10℃~50℃ (with air flow)

Storage Temperature

-20℃ ~60℃

Operating Humidity

95% @40℃, non-condensing

Mechanical

Dimensions

400mm(L)×320mm(W)×60 mm (H)

Material

High-strength and elegant Al-alloy panel

Weight

6.75kg/8.75kg (NET./GROSS.)

Color

Slivery/Black/White
