Atom D525 Network Gateway
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 per Month
- Shenzhen
- T/T Credit Card
You May Like
Product Details
| Products Status: | Stock | Type: | Embedded Computer | Brand Name: | Geshemtech |
| Model Number: | NPC-GS5610 | Place of Origin: | Guangdong, China |
Product Description
Specifications
Atom D525 Network GatewaySolution for Voip/Firewall/Gateway;
D525 1.8G Dual Core;6xRJ45;2xUSB2.0;1xMini IDE...
| Model | NPC-GS5610 |
| CPU | ATOM D525, 1.8GHz Dual Core |
| Chipset | Intel NM10 |
| BIOS | AMI BIOS 4/8Mbit |
| Memory | 2G DDR3 800/667MHz SO-DIMM 4G MAX. |
| Graphics | Onboard Intel GM 4150 Support DirectX 9.0 |
| Audio | N/A |
| LAN | 6*Intel 82583V 10/100/1000M |
| Storage Interface | 1xSATAll ; 1x44PIN IDE; 1xCF |
| Expansion Slots | 1xMini PCIe |
| USB | 2xUSB2.0 |
| Back Panel Connectors | 6xRJ45; 2xUSB; 1xCOM; RST_CT; DEF_CT |
| I/O Controller | 2xFan Connector(CPU&system); 1x4PIN DC Power Connector; 1x12PIN VGA; 1x7PIN PS2; 1xSerial PIN |
| Hardware Monitoring | CPU/system power fan speed detection; CPU/system temperature detection ; System voltage detection |
| O.S. | Windows XP/7,Linux,Win CE |
| Operating Temperature | 0°c~50°c |
| Structure | Front panel adopts aluminium alloy, 12mm high quality steel sheet for chassis |
| Dimensions | 482.6x250x44.2(LxWxH mm ) |
...
