Atom D525 1.8G ICH8M Chipset Firewall

Atom D525 1.8G ICH8M Chipset Firewall photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Embedded Computer
Brand Name:
Geshemtech
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Products Status Stock
Type Embedded Computer
Brand Name Geshemtech
Model Number NPC-GS5410
Place of Origin Guangdong, China

Specifications

1U Rackmount Network Computer Fanless Design
Onboard Intel Atom D525+ICH8M
Onboard 2G memory(Max to 4G)





Atom D525 1.8G ICH8M Chipset FirewallAtom D525 1.8G ICH8M Chipset FirewallAtom D525 1.8G ICH8M Chipset FirewallAtom D525 1.8G ICH8M Chipset Firewall



Test

Model NPC-GS5410
Display Feature 1xVGA Port
CPU ATOM D525,1.8GHz Dual Core+Intel ICH8M
Memory Onboard 2G ( MAX. 4G)
Hardware Monitoring CPU/system power fan speed detection; CPU/system temperature detection ; System voltage detection
Watchdog Timer 1~255 sec./min. Timer System Reset/Interrupt, Setup By Software
Storage 1x320GB  2.5' Hard Disk SSD/CF(Optional)
Ethernet 6xIntel 82583V 10/100/1000Mbps, One Bypass
Back I/O 2xUSB2.0 Ports;2xSerial Ports ; 4xRJ45
Panel I/O

Power Button; LAN LED

Mechanical And Environmental Dimensions:482.6x243x44.4  (LxWxHmm); Weight: 3Kg/4 Kg ; Reliability: MTBF≥50000h; MTTR≤0.5h ; Safety: GB4943 ; Operating Temperature : -10°C~50°C; Storage Temperature : -20°C~60°C; Operating Humidity: 10%~95%, non-condensing
Power Power Supply: 12V DC Power Input; Power consumption: 60W(Max)
Operating System Linux/ Windows 7/ Windows XP

Vibration 5-17Hz/1.0mm amplitude, 17-200Hz/1.0g acceleration
Shock 10g  Acceleration, 11ms Duration@HDD 50g  Acceleration, 11ms Duration@SSD
EMC GB9254-2008 class A
Noise ≤ 40 dB





...
