molybdenum and tungsten boat for vacuum coating industry
Description:
Tungsten evaporation boat manufactured by the special production line in our company can provide reliable guarantee of product quality for the customers. We adopt excellent tungsten materials with high purity, advanced techniques and special treatments to the product surfaces. Our company can produce tungsten boats for vacuum evaporation according to the customer drawing.
Applications of Tungsten Boat:
1.As a special and effective boat vessel, tungsten boat is widely used in electron-beam spraying as well as the sintering and annealing process in vacuum coating industries;
2.Tungsten boats are used for vacuum evaporation of materials in granular or pellet form;
3.They can also be used to evaporate small lengths of wire or to evaporate materials which would not properly "wet" the surface of an evaporation filament;
4.Tungsten evaporation boats are ideal for use in small evaporation systems for experimental and prototype work, such as bell jars.
Parameters of Tungsten Boat:
Type |
Thickness(mm) |
Width (mm) |
Length (mm) |
#207 |
0.2 |
7 |
100 |
#215 |
0.2 |
15 |
100 |
#308 |
0.3 |
8 |
100 |
#310 |
0.3 |
10 |
100 |
#315 |
0.3 |
15 |
100 |
#413 |
0.4 |
13 |
50 |
#525 |
0.5 |
25 |
78 |
Packaging & Delivery
Packaging: |
Wooden case with waterproof paper inner |
Delivery: |
10-25days(according to your qty) |
1,Tungsten&molybdenum profiles (rods,bars,tubes,plates,sheets of tungsten,molybdenum and their alloys).
2,Balance weight of tungsten heavy alloy (for motors,watches,golf clubes ,propellers).
3,Power automotive industry (tungsten copper switches,contactors,tungsten contactors)
4,Magnetron sputtering targets (flat panel displays,photovoltaic).
5,Vacuum coating industry (evaporation boat,cathode,evaporation coils,crucibles)
6,Quartz,glass and rare earth smelting industry (electrode,spinning nozzle,crucibles)
7,Parts for medical equipment (collimator device of CT machine,mammography target of X ray machine).
8,Electronics industry (ion implantation components,MOCVD machine parts,electron gun parts)
9,Nuclear aerospace and military industry (carrying boat,radiation shield,tungsten crucible for renewable nuclear fuel,rocket nozzle,throat,penetrator).
10,Vacuum or gas protected high temperature furnace material (sintering furnace,monocrystalline furnace,annealing furnace)
(1)Tungsten and molybdenum crucible(spinning,forging,sintering,welding),heating element.
(2) Heat shield,shelves,tray,hooks,seed holder,cylinder,pallet,screw,nut.
(3) Complete hot zone for sapphire crystal growth furnace (KY,ESG,CZ,HEM)
Achemetal Tungsten & Molybdenum Co., Ltd., located in Luoyang, Henan Province, China, is a manufacturer of tungsten and molybdenum specialty products. Our product line includes foil, sheet, plate, wire, rod, fabricated part as well as pressed and sintered part. Our products have been used in a wide range of industries, including electronics, lighting, semiconductor, automobile, fiberglass, aircraft, medical and many others. We are committed to serve customers, helping our customers and working with our customers to succeed in the ever challenging market.
