12V T10 Automotive Led Lights

12V T10 Automotive Led Lights thumbnail-1
12V T10 Automotive Led Lights photo-1
Negotiable MOQ: 20 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Other, reading lamp,license plate lamp,roof lamp,trunk lamp,turn signal lamp
Voltage:
12V
Lamp Type:
LED
Contact Supplier Request Quote Chat Now
Ningbo Yinzhou Masahiro Electron & Arts Inc.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, reading lamp,license plate lamp,roof lamp,trunk lamp,turn signal lamp
Voltage 12V
Lamp Type LED
Certification CE
Car Make universal
Place of Origin Zhejiang, China
Brand Name Zenyo
Model Number LD-T10-5SMD-5050

Specifications

Model number:LD-T10-5SMD-5050
Tai Wan imported 5050 chip
Five angle emitting,larger emitting area
High cost/Big solder joints

Working Temp:  -25°C~85°C
Storage Temp:  -40°C~125°C
Working voltage:  DC6-16V (DC13.5V)
Working Current:  0.31A
Reverse-Battery Protection:  YES
No-polarity:  YES
Maximum Output:  <=5W
Minimum Output:  >=4W
LED Kelvin:  >=8000K
LM per pc:  7~8LM
Luminous Angel:  120°
Chip manufacture: Taiwan Epistar
  FIVE ADVANTAGES
  Tai Wan imported 5050 chip
  Five angle emitting,larger emitting area
  High cost/Big solder joints
  Good quality conductor/better conduction
  High quality glass fiber board/higher heat resistance
  Wide range
  Five angle emitting design,wider emitting area
  FAST RESPONSE
  Do NOT need start up time
  Lighting in barely a second
  Low power consumption
  Led lower power dissipation
  Better protect vehicle circuit&Power saving
  Uneasy to oxidize
  Led without filament, great heat dissipation,low current,lower calorific value
  Circuit is Uneasy to be oxidized
  Stability
  Anti vibration,impact resistance,reliable,slow heating
  Revolutional solid state light emitter
  Longer life span
  Emitting hours can reach 50 000 hours in total
  Over 10times than the same output’s filament lamp
Products name: ZENYO car lighting, astigmatism ,LED width Lamp , reading lamp, door lamp ,
                            license plate lamp
Products model: LD-T10-5SMD-5050
Colour: blue white red gree yellow
Application:reading lamp,License plate lamp,Roof lamp,trunk lamp,turn lamp
Installation: same diameter as traditional light, can replace traditional lamp, do NOT need to be modified.
Structure: 1-9piece high LM 5050 epistar chip.
Lamp base type: wedge
Property:
        1.Energy saving:VS the same luminance filament lamp, Energy consumpt 1/10
        2.Longer life span:Emitting hours can reach 50 000 hrs in total, Over 10times than the same output’s
        filament lamp
        3.Environment friendly: do NOT contain lead,mercury etc
        4.High light: 10times luminance of the same output ’ filament lamp
        5.Radiation free:Anti UV and IR, user friendly
        6.Fast response:do Not need start up time, lighting barely need a second
        7.High stability:Anti-vibration, Impact resistance, Safe & reliable
