PEX Underfloor Heating pipes and tubes 20mm,25mm
- 2000 Ton / Tons per Month
- Dalian Port; Qingdao Port
- T/T L/C D/P D/A Credit Card
Product Details
Place of Origin: | Jilin, China | Brand Name: | Hongyuan | Model Number: | TZPEX202 |
Material: | PE | Specification: | 20*1.9; 20*2.0; 25*2.3 | Length: | 200m/coil; 300m/coil. |
Thickness: | 1.9mm--2.3mm | Standard: | ISO;Bureau Veritas; GB/T18992.2-2003 (National Standard) |
Product Description
Specifications
PE-Xa heating coil is used for floor heating/radiating systemLong service time
Qualified
100% raw material is LG Chem DX1800
PE-Xa Heating Pipe Coil
The PEX pipe contains many advantages including non-scaling, non-pollution, non- toxic and non- smell in home heating and most housing applications. With high resistance to aging, heat and pressure, elastic memory function, good thermal insulation and anti-freezing features, the pipe is safer and more efficient.
Application of PEX Pipe:
As a key type of Building Material, it is widely used in the following fields:
--PEXa under-floor heating system
--PEX Plumbing system
Features:
1. Easy installation and sufficient accessories
The PEX pipe acquires easy installation and sufficient accessories due to the flexibility, less but special pipe fittings. Even without tap threading, die threading or welding, it can be matched with the standard pipe fitting.
2. Advanced technology and imported materials
With advanced equipment from North Korea, one-step Monosil PEX producing technology, Computer monitoring system, totally enclosed automatic feeding system, advanced technology processes, perfect testing instruments.we used imported materials LG Chem XL1800 which are compliant to the GB/T18992.2-2003 standard to ensure the high performance of the pipe. Steam-pressure cross-linking technology is used to reduce the longitudinal shrinkage.
3. Stable production and satisfying customers' requests
Yearly production capacity reached 2000T(20,000,000m).We also promise quick delivery and production with customized size.
Unit price(FOB Dalian): $0.36
tube wall thickness tolerance:+/- 0.05mm
Production Description:
- Name: PE-Xa (Peroxide crosslinked polyethylene)heating coil
- Material: PE-Xa (Peroxide crosslinked polyethylene )
- Place of Origin: Jilin China (Mainland)
- Specification: 20*1.9, 20*2.0, 25*2.3
- Pressure Rating: 1.25MPa, 1.6MPa, 2.0MPa ,2.5MPa
- Color: transparent white or other colors as your request
- Standard: DIN8077/ 8078(German standard). GB/T18992.2-2003 (National Standard)
- Factory Certification:ISO; Bureau Veritas ; GB/T18992.2-2003 (National Standard)
Item | Specification | Package |
PE-Xa Heating Pipes | Φ20*1.9 | 200m/roll,300m/roll |
Φ20*2.0 | 200m/roll,300m/roll | |
Φ25*2.3 | 200m/roll |
Inner Packing:
Application Domain:
1. warm-water heating pipe: residence, market, hotel, gym, hospital etc.
2, Hot-water heating system: common bathing pool, hot spring, indoor swimming poor.
3, soil warming& heating system: parking lots, power plant, square, road.
4, warm-water heating pipe for crops and livestock products.
5, industrial pipe: heat exchanger, heating coil, liquid transferring pipe.
Comparison:
Radiator heating effect :
No crosslinked polyethylene material, the heating effect is scattered and wasteful.
PE-Xa pipe heating effect:
With crosslinked polyethylene material,the heating effect is concentrated and energy conservation.
ISO 9001:2008 Certificate:
Trademark Registration Certificate:
WHY choose us to cooperation?
About us:
Outstanding advantages as below:
1. Authenticity and Reliability: Jilin Tianze Pipe Industry Co., Ltd. is a verified company by some professional third-party inspection companies: ISO, BV (BUREAU VERITAS) and .
2. Patented product——Manifold: This is designed and developed individually by our independent R&D team. Especially using plastic instead of steel/copper is a great advance.
3. Production facilities are imported from South Korea: Computer monitoring system, totally enclosed automatic feeding system, advanced technology processes, perfect testing instruments.
4. Main raw materials: South Korea LG raw materials (XL1800), SK global chemical DX 800 and HONAM 8100GX, without any reclaimed filler or damaged material in the products.
5. Accessories: imported from Japan and Europe. Such as Germany Degussa DTBP cross-linking agent, Switzerland CIBA A/O1076 major antioxidants, PS802FL auxiliary antioxidants.
6. Years of production & service experience: High-quality products, Customer First..
7. Stable domestic market and stable stock.
Corporate Culture:
Our vision:Provide high-quality green environmental protection pipe system for construction industry.
Our targets: Mutual respects, excellent service, commit improvement, create values
Our management concept: Humanized, militarize and scientific
Our service concept: Thankfulness, dedication, sincerity, high efficiency and win-win
Our mission: Create the outstanding brand in the plastic pipe field.
Our motto: Development and innovation is of top priority.
We are the manufacturer specialized in producing many different kinds of pipes and fittings more than 6 years, mainly dedicated to developing and producing “Hongyuan” brand PE-Xa heating pipes, PE-RT geothermal pipes, PP-R hot/cold water pipes, PP-R fittings and manifolds.
If you are interested in any products, please feel free to contact us for more information at anytime.
