TSD Series servo AC voltage stabilizer
Hanging type voltage regulators (TSD type):
TSD-3KVA, TSD-4KVA, TSD-5KVA, TSD-6KVA, TSD-7KVA, TSD-8KVA, and TSD-10KVA
TSD series servo-type AC voltage stabilizers are perfectly designed on the basis of the series SVC (TND) products. They possess the protection against time-delay, over voltage and under voltage and the free switching between the electric supply and voltage stabilization. They adopt the hanging type installations, which can effectively save and make use of space. The soft overall color of streamline gives people a bright and new look.
Parameters:
Input voltage: 150-250V (1P)
Output voltage: 220V or 110V
Stabilization accuracy: 220V±3% or 110V±6%
Frequency: 50Hz/60Hz
Delay time: long 5m±2m; short 5s±2s
Overload power factor: 0.8
Efficiency: ≥90%
Dielectric strength: 1,500V/min
Ambient temperature: -10±40°C
Relative humidity: ≤90%
Over voltage protection: 246±4V
Under voltage protection: 184±4V
Wave form distortion: no additional waveform distortion
Insulation resistance: ≥2MΩ
