Specifications
rubber squeegee blade1.Color:red,blue,green
2.Material:PU
3.Customer's size
4.Competitive price
China Water-proof Screen Printing Rubber Squeegee Blade(Direct Supplier)
About us
Shenze Jiamei was founded in 1999,located in shenze.Our company mainly produce and supply aluminum screen printing frame,squeegee,aluminum handle,We have technicist with abundant knowledge and a lot of practice in this line.
Our company has a good reputation and a large number of customers in Europe, the Americas, Africa, the Middle East, Southeast Asia and other countries and regions.
We hope that our high-quality products, the solid reputation, the most favorable price can built a bridge to glory with you.
Rubber Squeegee Blade introduce
Screen print squeegee is also called scraper, it is one kind of tool that used to scratch the ink on the screen to make it leak to the substrate.
Squeegee is made by the combination of scratching strip and handle, rubber blade is inserted into the wood handle and stapled in position, then professionally sharpened after assembly. Use for both graphic and textile applications, for all hand printing and many machine applications.
Rubber Squeegee Blade hardness selection
Low hardness | 55,60,65 SHORE A | red,natual color |
Medium hardness | 70,75 SHORE A | Green,natual color |
High hardness | 80,85 SHORE A | Blue,natual color |
Super hardness | 90,95 SHORE A | White color |
Triple Layer: Medium hardness | 75/90/75 SHORE A | Green/white/green color |
Triple Layer: Low hardness | 65/90/65 SHORE A | Red/white/red color |
Other hardness and colors are available on request | ||
Rubber Squeegee Blade specification
Rubber Squeegee Blade types
Rubber Squeegee Blade classifacation
AS Series
Using high-quality raw materials,stable quality ,with wear-resistant common solvents,good elasticity,used in textile printing and general patterns
AM Series
Using high-quality raw materials,stable quality, good solvent resistance,abrasion resistance.used for general pattern printing.
AA Series
Using imported raw materials,stay in grade,solvent resistance,easy to grind and long service durability,apply for advertising,electronics,packing,tobacco and other standard mechanical printing.
AQ Series
Imported raw materials and equipment.Excellent solvent resistance,abrasion resistance,sharp knife grinding leveling can be repeated,especially for glass printing and some high-end printing.
AD Series
Imported raw material,imported equipment.With superior solvent resistance,abrasion resistance,stability,especially for the electronics industry,suitable for all areas of high-grade printing.
Three layer scraper Series
Three layer scraper has triple hardness,include a hard part between(90 degrees)make the sword scraping ink increase angle,to reduce the amount of ink attached,soft part(60 degrees-70degrees)can reduce the sword scraping ink printing interface to the damage
Rubber Squeegee Blade packing
plastic package inner and catron outer or as customer request
Rubber Squeegee Blade feature
1.Our squeegee made of special polyurethane elastomer have the following advantages.
2.High abrasion resistance and tear resistant better elasticty resulting in prints of uniformly high quality material.
3.Excellent resistance and minimum swell to a wide range of pastes,inlss and solvents.
4.Precisely finished edge.
Rubber Squeegee Blade application
1.screen printing industry.
Use to scrape the screen printing solvent liquid, and make to get the equisite pattern
2.Photography printing industry
Used in photography printing to dry the photographic paper after it is washed,preventing wrinkles or water sports
3.Window film,Car vinyl film, Ceramic and Sanitaryware design in ceramic industry
Use to scrap the thin film sticked on the window, make film very flat.
Or scrape vinyl film, make to achieve bubble free application.
4.Electronic industry.
To crape circuit board.
If you are interested in our rubber squeegee blade please contact me as sonn as possible!
High quantity and best price
Shenze Jiamei Screen Printing Co.,Ltd.---Your Best Friend And Business Partner.
