Hinge joint fencing is the best choice of ranchers for protecting the jumping animals like deers, horses and cows, sheep and goats. The hinge-knot system ensures proper stretching and allows for easier installation over hilly or rough terrain. Uses of our hinge-joint knots allow the fence to give under pressure and spring back into shape. The heavy zinc coating of the wire offers the finished fencing good rust resisting and corrosion.
Common hinged joint fencing is made from galvanized wire with a wire diameter of 2.5 mm and the top and bottom wire are made with wire diameter of 2.8 mm. Fence height is normally from 0.8m to 2m. A variety of heights, hole mesh, spacing and styles are offered for more choices.
Material: Steel wire with high strength, with zinc coating layer and without.
Features:
Hinge joint fence is simple in structure, easy for maintenance, it has short installation period, less weight, easy for transport and easy ventilation.
High of roll: 0.8M to 2.0M
Length per roll: 50M/100M/200M
Specification Informations:
| STANDARD SPECIFICATIONS | ||||||
| Net style | No. Line Wires | Top & Bottom Line | Intermediate Line | Distance between | Roll Height ( cm) | Roll Length(m) |
| Wire Dia (mm) | Wire Dia(mm) | Stay Wires (cm) | ||||
| 6/60/15 | 6 | 2.5 | 2.0 | 15 | 60 | 50 |
| 6/80/15 | 6 | 2.5 | 2.0 | 15 | 80 | 50 |
| 8/80/15 | 8 | 2.5 | 2.0 | 15 | 80 | 50 |
| 9/80/15 | 9 | 2.5 | 2.0 | 15 | 80 | 50 |
| 8/100/15 | 8 | 2.5 | 2.0 | 15 | 100 | 50 |
| 11/100/15 | 11 | 2.5 | 2.0 | 15 | 100 | 50 |
| 9/120/15 | 9 | 2.5 | 2.0 | 15 | 120 | 50 |
| 13/120/15 | 13 | 2.5 | 2.0 | 15 | 120 | 50 |
| 13/150/15 | 13 | 2.5 | 2.0 | 15 | 150 | 50 |
| 15/150/15 | 15 | 2.5 | 2.0 | 15 | 150 | 50 |
| 17/200/15 | 17 | 2.5 | 2.0 | 15 | 200 | 50 |
| Other special specification is available by customer request. | ||||||
