Specification Razor Blade Specification:
Reference Number |
Thick |
Wire Dia |
Barb Length |
Barb Width |
Barb spacing |
BTO-12 |
0.5 |
2.5 |
10 |
13 |
26±1 |
BTO-18 |
0.5 |
2.5 |
15 |
15 |
33±1 |
BTO-22 |
0.5 |
2.5 |
22 |
15 |
34±1 |
CBT-65 |
0.6 |
2.5 |
65 |
21 |
100±2 |
Barbed Tape Concertina (BTC);Barbed Tape Obstacle (BTO)
Standard materials are either galvanized or stainless steel.
Standard packages products are shown in the tables above, special specifications available on request.
Barbed Tape Wire Specification:
| Outside Diameter | No. of Loops | Standard Length per Coil | Type | Notes |
450mm |
33 |
8M |
CBT-65 |
Single coil |
500mm |
41 |
10M |
CBT-65 |
Single coil |
700mm |
41 |
10M |
CBT-65 |
Single coil |
960mm |
53 |
13M |
CBT-65 |
Single coil |
500mm |
102 |
16M |
BTO-10.15.22 |
Cross type |
600mm |
86 |
14M |
BTO-10.15.22 |
Cross type |
700mm |
72 |
12M |
BTO-10.15.22 |
Cross type |
800mm |
64 |
10M |
BTO-10.15.22 |
Cross type |
960mm |
52 |
9M |
BTO-10.15.22 |
Cross type |
CBT-65
BTO-22
Concertina wire is supplied typically in single coils or crossed spiral coils. We can produce razor type barbed wire in concertina coils or straight lines. Blade types and specifications vary according to the customers’ requirements.
Concertina wire (coil) is made by stainless steel sheets and galvanized high tensile claps. It has a beautiful crossing outlook and it is suitable for uses after extending, making an ideal security fencing with great anti-climb and anti-cutting property.
Standard materials for razor type barbed wire are either galvanized or stainless steel.
Main Application: Concertina wire (coil) is used as security fencing and isolation for gardens, residences, military sites and other sites requiring high security.
