With combined experience of over 15 years, Senke has established itself as a reliable and dependable Manufacturer of Wire Mesh Partitions.
Wire Mesh Partitions are perfect for most Tool Room, Stock Rooms, Departmental Divisions and other restricted areas. Security Cages Wire Mesh Partitions can also be custom made to order by our design engineers to fit any situation.
Wire Mesh Partitions non-bearing panels are North American standard size, and are built rugged to withstand tough punishment. Wire Mesh Partitions panels are interchangeable and can be rapidly adapted to any need. Our Wire Mesh Partitions allow for maximum air circulation. Diffuses lighting for better illumination and won't obstruct fire hose stream.
Wire Mesh Partitions are the ideal solution for any secure environment. Panels, doors, and service windows can be arranged in any combination. They are attractive, economical, quick to install, and permit expansion at any time.
Wire Mesh Partitions are easy to install. No fabrication is necessary.Simply bolt the Wire Mesh Partitions panels together and anchor to the floor.
We manufacture wire mesh partitions,wire mesh railing infill panels,wire mesh window guards and woven wire products.
Specifications
- Mesh: 1 ½” intermediate crimp woven diamond mesh.
- Wire: No. 10 gauge steel wire
- Vertical Frame: 1 ¼” x 5/8” C-Section channel with ¼” Bolts at 15” on center.
- Horizontal Frame: 1” x ½” channel, joints are mortised and tenoned.
- Center Reinforcement: Two 1” x ½” channels riveted toe to toe through the mesh
- Top Capping Bar: 2 ¼” x 1” channel with ¼” bolt holes approximately 24” on center.
- Corner Post: 1 ½” x 1 ½” angle
- Floor Sockets: 1 ¼” x 1 ¼” x 2” high aluminum or cast iron floor shoes.
- Line Posts: For free standing partitions, 3” x 4.1 channel with a 10” x 3 ½” x 3/8” base plate, use approximately every 15’ to 20’.
- Hinged Doors: 1 ¼” x ½” channel with 1 ¼” x 1/8” flat bar cover all sides. Each door to have 1 ½ pair of butt hinges.
- Sliding Doors: 1 ¼” x ½” channel with 1 ¼” x 1/8” flat bar cover all sides. Each door to have 4 wheel roller bearing hangers, box track, and bottom guide.
- Hardware: Mortise lock and cylinder operated by key outside and recessed knob inside or padlock hasp.
- Sheet Metal Base: Available with 16 gauge sheet in lower portion.
Finish: Electrostatically applied enamel paint (Standard Colors: Gray and Black) or hot dipped galvanized.
