Titanium Wire
1.Material: Gr1, Gr2, Gr3, Gr4, Gr5, Gr7, Gr9, Gr11, Gr12.
Standard: ASTM B348/863, ASTM F67/136.
2.Diameter:
Straight:
Dia.: 1.0mm-5.0mm ( tolerance: +/-0.05mm)
3000mm max length
Coiled:
Dia.: 0.5mm-5.0mm (tolerance: +/-0.05mm)
Spool diameter: around 300mm.
3. Surface: Polish surface, acid wash surface
4. Feature: Low density, high specific strength, high corrosion resistance and good thermal stability.
5. Applications:
Medical, aerospace, military, petrochemical engineering, metallurgy, electroplating,
Vacuuming metalling, sports, medical, sporting goods, glasses, earrings, hair accessories, rack plating, welding, etc.
Shape: Coil or straight.
Package: Each coil is twined with a soft paper, then trussed with metal wire and packed into wooden cases last.
Special requirements for the diameter and length also could be produced as well, as per the requests in details.
| Grade |
GB: TA0, TA1, TA2, TA3, TA4, TA5, TA6, TA7, TA9, TA11, TA15 TB3, TB8, TB9 TC1, TC2, TC3, TC4, TC6, TC9, TC10, TC11, TC12, TC17, TC21. |
| ASTM: Gr1,Gr2,Gr3,Gr4,Gr5,Ti6Al4V ELI,Gr7,Gr9,Gr12, Gr23 Ti-6Al-7Nb, Ti-15Mo-5Zr-3Al, Ti-10V-2Fe-3Al, Ti-15V-3Cr-3Sn-3Al, Ti-6Al-2Sn-4Zr-6Mo, Ti-6Al-2Sn-4Zr-2Mo, Ti-6Al-6V-2Sn-0.5Fe-0.5Cu, β-C(Ti-3Al-8V-6Cr-4Mo-4Zr), Ti-15Mo, etc. | |
| Standard | GB/T13810-2007, GB/T2965-2007 |
| ASTM B 348, ASTM F 67, ASTM F 136, AMS 4928, MIL 4911, ISO 5832-2, etc. | |
| Size |
Diameter: Coil wire: Min. 0.1mm Max 12mm Straight wire: Min 0.8mm Remarks: Special requirements for the diameter and length also could be produced as well, as per the requests in details. |
| Applications | |
| Medical, aerospace, military, petrochemical engineering, metallurgy, electroplating, vacuuming metalling, sports and so on. |
