Cheapest!!! led car door logo laser projector light

Specifications

4D car badge light/LED badge Lights/ badge lamp
all tyle logo are available for your choices

Specifications

4D car badge light/LED badge Lights/ badge lamp
all tyle logo are available for your choices

4D car badge light /LED badge Lights/ badge lamp



User manual:
1.This product is specially designed for auto modification fancier; we purpose to bring more driving fun to drivers;



2.This product can be used in daytime and at night. It should be installed in the original car space on the car trunk.



3. This product is a laser and reflective badge in the daytime.



4.When the vehicle license plate light is turned on, the car badge background light also will be starting to work and the badge of trunk will be illuminated. It looks like very beautiful and cool.





Specifications:
1.Power supply: DC 12V+/-10%

2.Power cable length: 0.6meter





Installation:



1. First, spread a towel beside the car trunk (in order not to scratch the car body), with a flat head screwdriver, pry the car logo







2.Tear off the double-sided adhesive: pry it from the car body with moderate strength, steps by steps, slowly pry it down, then clean up the logo and car body .







3 Use crosshead screw-driver to uninstall the board inner the trunk,



There are clips at somewhere, please carefully remove the insulation board ,you can see all kinds of lines.







4. Pass the power line of Car logo lamp through one of the logo location hole, pass inside the trunk and tear off the back of vehicle logo light







5. As the car logo lamp has installed, now connect the power supply.



The logo lamp should connected with the light power supply of the rear license plate ,so that when turn on the small night lamp, the car logo lamp is also turned on



Find the license plate lamp power connector



6. First pull the plug, and strip a opening separately of the positive and negative pole to show the wire core, Connect the lines(red to red and black to black) ,don't forget to wind then with insulating tape, Also, you need to plug back and set the insulation board to the trunk again!



Attention:

Please access power supply through voltage regulator rectifier. DO NOT direct access to car battery.

1.We strongly suggest installing this product by Professional Automobile Modify Factory or Workshop. The manufacturers disclaim all responsibility for belongings or personal casualty caused by improper installation or misuse.
2.Our company does not responsible for the legality of installing this product, before installation, contact the vehicle management department for confirmation or filling.
If you bid this list, you will get only one pc which same color in one picture. These item pictures in the gallery is only for show you how many colors we have. The default color of this listing is BLUE, so if you like other color, please leave me a message when paying (There are three colors can be choose: White, Red and Blue) ,Please tell me what color you want.
