High Pressure Steel Wire Knitting Rubber Hose

High Pressure Steel Wire Knitting Rubber Hose thumbnail-1
High Pressure Steel Wire Knitting Rubber Hose photo-1
US$ 1 - 6 MOQ: 500 Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
Tiger
Model Number:
high-pressure rubber hose
Contact Supplier Request Quote Chat Now
Shijiazhuang Sothink Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name Tiger
Model Number high-pressure rubber hose

Specifications

rubber hose
1. NBR oil resistant synthetic rubber
2. Steel wire knitted to strengthen
3.High and low pressure resistance

rubber hose

Working temperature for high pressure rubber hose

1.Oils -40°C to 100°C

2.Air -30°C to 50°C

3.Water emulsion Under +80°C



Application for high pressure rubber hose

1.Used in mine hydraulic support,oil exploration,crane transport,mining equipment

2.Carry hydraulic fluids such as mineral oil,soluble oil,feuls,lubrication,water,emulsion,oil-water emulsion and air.



Techonicial specification:





Hose code(Mpa) Hose I.D(mm) Hose O.D(mm) Layer O.D(mm) Max. Operation Min. burst pressure Min. bend radius(mm) Unit Weight
MPa PSI MPa PSI Kg/m Ib/ft
1-φ5-21 5±0.5 12.7±0.8 9.5±0.6 21 3043 63 9129 90 0.3 0.019
1-φ6-21 6±0.5 16±1.0 11.7±0.6 20 2898 60 8694 100 0.34 0.021
1-φ8-17.5 8±0.5 18±1.0 13.7±0.6 17.5 2536 52.5 7608 115 0.42 0.026
1-φ10-16 10±0.5 20±1.0 15.7±0.6 16 2318 48 6954 130 0.47 0.029
1-φ13-14 13±0.5 24±1.2 19.7±0.8 14 2028 42 6084 180 0.64 0.04
1-φ16-12 16±0.5 27±1.2 22.7±0.8 12 1739 36 1217 205 0.7 0.044
1-φ19-10 19±0.5 30±1.2 25.7±0.8 10 1449 30 4347 240 0.84 0.053
1-φ22-9 22±0.5 33±1.2 28.7±0.8 9 1304 27 3912 280 0.95 0.059
1-φ25-8 25±0.5 37±1.2 32.2±0.8 8 1159 24 3471 300 1.09 0.068
1-φ32-6 32±0.7 44±1.5 39.2±0.8 6 869 18 2607 420 1.38 0.086
1-φ38-5 38±0.7 50±1.5 45.2±0.8 5 725 15 3042 500 1.8 0.115
1-φ51-4 51±1.0 63±1.5 58.2±0.8 4 579 12 1737 630 2.8 0.175
1-φ64-2.5 64±1.0 75±1.5 71±0.8 2.5 362 7.5 1086 770
1-φ76-1.5 76±1.0 88±1.5 84±0.8 1.5 217 4.5 651 930
1-φ89-1 89±1.0 103±1.85 9.9±0.8 1 144.9 3 435 1100
1-φ102-0.8 102±1.0 115±1.5 111±0.8 0.8 116 2.4 348 1250
2-φ5-60 5±0.5 15±0.8 11.2±0.6 60 8694 180 26082 90 0.4 0.025
2-φ6-60 6±0.5 18±1.0 13.5±0.6 60 8694 180 26082 100 0.45 0.028
2-φ8-50 8±0.5 20±1.0 15.5±0.6 50 7245 150 21735 115 0.62 0.039
2-φ10-40 10±0.5 22±1.0 17.5±0.6 40 5796 120 17388 130 0.71 0.044
2-φ13-30 13±0.5 26±1.2 21.5±0.8 30 4347 90 13041 180 1.93 0.06
2-φ16-21 16±0.5 29±1.2 24.5±0.6 21 3043 63 9129 205 1 0.063
2-φ19-18 19±0.5 32±1.2 27.5±0.8 18 2608 54 7824 240 1.23 0.077
2-φ22-16 22±0.5 35±1.2 30.5±0.8 16 2318 48 6955 270 1.18 0.086
2-φ25-14 25±0.5 39±1.2 34±0.8 14 2028 42 6084 300 1.54 0.096
2-φ32-11 32±0.7 46±1.5 41±0.8 11 1594 33 4782 420 1.92 0.12
2-φ38-10 38±0.7 52±1.5 47±0.8 10 1449 30 4347 500 2.44 0.153
2-φ51-8 51±0.7 65±1.5 60±0.8 8 1159 24 3477 630 3.38 0.212
2-φ64-4 64±0.7 77±1.5 73±0.8 4 579 12 1738 790
2-φ76-3 76±0.7 90±1.5 86±0.8 3 434 9 1302 950
2-φ89-2.5 89±0.7 105±1.5 101±0.8 2.5 362 7.5 1086 1130
2-φ102-2 102±0.7 117±1.5 113±0.8 2 290 6 870 1280





Photos of high pressure rubber hose

high pressure steel wire knitting rubber hose



rubber hose



If you have any kind of question , please feel free to contact us .
