Sintered Wire Mesh With Perforated Metal

Sintered Wire Mesh With Perforated Metal photo-1
Sintered Wire Mesh With Perforated Metal photo-2
Sintered Wire Mesh With Perforated Metal photo-3
Sintered Wire Mesh With Perforated Metal photo-4
Sintered Wire Mesh With Perforated Metal photo-5
Sintered Wire Mesh With Perforated Metal photo-6
US$ 50 - 100 MOQ: 50 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Material:
Stainless Steel Wire
Type:
Weave Wire Mesh
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Xin'gang
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hebei, China
Material Stainless Steel Wire
Type Weave Wire Mesh
Application Filters
Weave Style Plain Weave
Wire Diameter 0.80mm - 0,06mm
Technique Woven
Model Number S5-layers
Brand Name Generalmesh

Sintered wire mesh with perforated sheet filter plate and tube

Sintered wire mesh with perforated metal specifications:
Filter raiting: 2um-200um.
Materials: SUS 304, 316, 316L; or Alloy Steel Hastelloy, Monel, Inconel.
Standard size: 500 × 1000mm, 600 × 1200mm and 1000 × 1000mm, 1200 × 1200mm.



Sintered wire mesh with perforated sheet is made from several layers of stainless steel woven wire mesh and a perforated metal layer sintering together, usually consisting of five layers (as the left picture shown) - perforated layer, buffer layer, fine mesh, protective layer and filer layer. The above layers are sintered together to form a very study and strong multi-layers filter mesh. The perforated metal as reinforcement layer support the filter structure, which has very high compressive and mechanical strength.



Features: this type sinter mesh filter are resistant corrosion and high temperature, with wide filter rating ranges, having high mechanical strength and the ability to maintain a steady filter rating under high pressure. It is also easy to clean with a variety of filter cleaning techniques, and easy to fabricate, weld, punch, shear or made to filter cartridges and tube.




Sintered Wire Mesh with Perforated MetalSintered Wire Mesh with Perforated Metal
