2014 Unique Luxury Wedding outdoor used party tent

Specifications

Party Tent
1.Aluminum alloy ,firm and durable
2.Easy to assemble
3.Use for the family party,organization activities
4.TUV







Feature:

 1. Unit combination style structure. The span is from 6meters to 10 meters, and the length is unlimited.

 2.The Long Span Size such as:15 meters,18 meters,20 meteres,25 meteres,30 meteres.Each length 5 meteres increasing .



Application:



Widely used for exhibition, sports games, celebrations, party, wedding, warehouse and so on.







Tent Technical Information	Small Tent		Medium Tent		Large Tent
Clear span width   (W)	5-10m		10-15m		15-20m
Bay distance   (B)	3m		5m		5m
Eave height (h)	3m		3m		3.5m
Ridge height (H)	4.5-5.5m		5.5-6.5m		6.5-7.5m
Max. length	No limited		No limited		No limited
Main profile	81.5x47.6x2.0mm	60x40x2.0mm	120.4x66.4x2.5mm	120x80x2.0mm	194.4x108.4x3.5mm	120x80x2.5mm
Frame material	Hard pressed extruded aluminium	Iron, with powder coating	Hard pressed extruded aluminium	Iron, with powder coating	Hard pressed extruded aluminium	Iron, with powder coating
Fabric material	450g/m double PVC coated polyester textile, waterproof & flame retardant		650g/m double PVC coated polyester textile, waterproof & flame retardant		850g/m double PVC coated polyester textile, waterproof & flame retardant



Frame Material:

1)High-strength aluminium alloy, galvanized to rust resistance.

2)Connecting parts are made of zinc powder-coated steel.

3)The frame is strong,durable,light in weight,not easy to rust and distort, can last for above 10 years



Roof Cover and Sidewalls Material:

1) Double layers PVC-coated polyester textile, many colors are selectable.

2) Side wall weight:650g/sqm     Roof cover weight :850g/sqm

3) Max-allowed wind speed:80km/h

4) Waterproof, flame retardant to DIN4102 B1, M2, UV resistant.



Advantages & Features of Party Tent :

1)Modular design, easy to be extended or decreased

2) It can resist 100km/h wind speed

3)Snow load:75kg/sqm (sanow can't stay if use big degree roof design)

4)Allowed temperature condition:-30 degree celsius ~+70 degree celsius

5)Durable, easy to be set up and dismantled,removeable

6)Sizes can be customized(like side/height,shape)



Optional Accessories:

1)PVC Roof Cover:  opaque PVC, transparent PVC ,colorful PVC

2)Sidewalls: PVC sidewall (with transparent windows), glass wall, ABS soild wall ,sandwich wall

3)Doors: double-swings glass door, sliding glass door, rolling door ,ect.

4)Indoor Decorations: roof lining, sidewall curtain,lighting,carpet,ect.

5)Wooden Flooring System;

6)Ground Fixed: steel nail, expnding scew, weight plate;

7)Rain Gutters(inner roof bean rain gutter or rain gutter between two tents)

Foshan City Shunde District Chuangcai Tents Co., Ltd is one of the pioneers in this filed who has introduced advanced technologies in design, develop and manufacture of types of outdoor products, such as folding tent, car canopy, retractable awning, big party tent, high peak gazebo, etc. The company was established in 1996. The 16 years tent manufacturing experience make our factory have the rich cultural background and professional experience.

Our products have all range of the sunshade products. Not only have the first rate R&D department, we also have the professional international sales department together with our production department to provide our best service and good quality products.



We sincerely welcome our friends all over the world to contact us for long-term business cooperation!!!
