Made In China 20W fiber laser marking machine
- 500 Set / Sets per Month
- Shenzhen/Guanzhou/HK/Chongqing
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
Condition | New | Laser Type | Fiber Laser | |
CNC or Not | Yes | Cooling Mode | Air Cooling | |
Control Software | EZCAD | Graphic Format Supported | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT | |
Working Accuracy | 0.01mm, ±0.01mm | Place of Origin | Chongqing, China | |
Brand Name | BENDE | Model Number | BD-S20G | |
Power(W) | 10w/20w/30w/50w | Certification | CCC, CE, CE, SGS | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Made In China 20W fiber laser marking machine , optical mini portable fiber laser marking machine,high precision mini portable fiber laser marking machine,It can engrave and mark on the surface of many metal and non-metallic ,widely used in the marking of below area :industrial bearings,gear,various automobile components,hardware tools,aerospace components,IC chip,computer accessories,watch,electronic and communication products,wire and cable,food package,jewelry etc .
BENDE Fiber laser marking machine :
1.High electro-optic conversion efficiency;
2.Low power consumption, stability laser output;
3.High quality beam, consumable free,small machine dimension ;
4.Smaller output laser beam , finer marking line.suitable high precision marking;
BenDe Machine Factory Promise:
1:All machine 1Year guarantee!
2:After get the machine accept 7 days return the goods!
Model | BD-S20G |
Laser types | Fiber laser generator |
The average output power | 10W/20W/30W/50W |
Laser wavelength | 1064nm |
Standard marking area | 110*110mm(Option:200*200/250*250/300*300mm) |
Frequency | 20KHz-80KHz |
Repetitive accuracy | 0.003mm |
Min Linear Width | 0.01mm |
Marking Depth | ≤1mm |
Marking speed | ≤8000mm/s |
Consumed power | <500W |
Computer Operating System | Win98/Win2000/XP |
Cooling system | Air cooling |
Power Supply | 220V/ 50HZ-60HZ/15A |
Min character | 0.15mm |
Working Accuracy | ±0.01mm |
Laser Module Life | >100000hours |
Guarantee | 1Year |
Fiber laser marking machine marking material includes metal such as gold,silver,copper,aluminum,stainless steel,hard metal alloy ,chromeplate,titanize etc, and other non-metallic material such as ceramic,PVC,plastic,epoxy resin,leather and so on .
In the spirit of responsibility for the customer, our company keeps tight follow-up with product quality, visits our customers periodically, adopts the suggestions from our customers, and offers the all-day, all-directional and top-grade market services.
The technical and after-sale services are listed as follows:
1. Provide free technical training, guidance and information of accessories. One-year warranty is provided. (The detailed reference will be written into the final contract.)
2. Our technical staff could instruct our customers on the installation of connector and accessories on site, and deal with technical and quality issues.
3. We guarantee more than 10 years’ service life of our products with 2 years’ warranty and life maintenance.
4. 24-hour hot line: 86- 15803070574. Once receive the customer complaints, we will response within 24 hours.
5. Free maintenance and replacement will be provided if defects result from quality failure of our product.
6. Our company will provide technical services by phone, fax, email, etc., please refer to the contact details.
7. Our company will implement the contract strictly; deliver the products to location specified by our customers for free in accordance with the mode of transportation.
8. Our company will provide perfect after-sale services and technical support.
Once receive the calling of complaints, we will respond to it within 12 hours at working time and provide solution within 48 hours. If necessary, our company will send technical staff there and provide on-site solution.
1.Durable wooden case or as per required.
2.The delivery lead time would be 7 working days after recieving the payment.
3.As for the wholsalers/distributors, we could send the cargo by air, by sea or by railways via reliable forwarder.
4:Computer & laser mark soft ware system
Portable type equipped notebook with English system
Desktop type equipped LCD and industrial compute, (PC the English laser marking soft ware installed), Marking system and control card made in Germany,
5. We will give customer the fixed tools for helping to fixed the focus distance.
6. With foot switch.
7: One-year warranty is provided. (The detailed reference will be written into the final contract.)
8: Professional staff for installation and training if needed
BenDe Machine Factory are specializing in producing,developing and selling laser marking machine,laser welding machine,air tapping machine,servo electric servo tapping machine etc.It is Chinese industrial laser processing equipment pioneer ,domestic well-known marking equipment manufacturer.And,with rich experience ,we also have obtained huge success in international market ,the mainly foreign markets are United States, Germany, Spain, Russia, Singapore, Indonesia...more than 30 countries and regions .Till now, a lot of customers all over the world have visited us.
