Specifications
automatic door controller1. Euro-type
2. Work with 100watts motor
automatic door controller
| Door style | single leaf or double leaf |
| Door width | 650mm~1300mm |
| Door weight.max | 200kgs 150kgsX2 |
| Power supply | 90VAC~250VAC, 50/60Hz |
| Voltage output | 12V DC, 24V DC |
Brushless Motor |
100W,24V DC |
| Opening speed and closing speed | 250~550mm/S |
Creep speed |
20~100mm/S |
| Manual opening Force | <50N |
| Hold-Close Force | 150N<f<250N |
| Hold-open time | 2-20s (adjustable) |
LT-190A New Feature Description
1. LT-190A Program have considered the door weight, the doors won’t collide
when randomly setting.
2. The value of random adjustable parameter is set to minimum, the door still
can open and close freely;
3. In the safety zone, resistance is minimum, when door opens / close in the
security zone, people will not be pinched.
4 Immediate rebound when encountering resistance, and pass through with
low speed next time.
55. If two consecutive encountering resistance, the door will pause, until get a
opening signal, then the door opens.
6. When the door is in a static state, after you change the doors position, the
doors won’t collide if there is opening signal again.
7. When the door is in open or closed state, if there is the external force, the
motor has an immediate reaction force, if external force withdrawals
In addition, motor recovers to normal state (the size of the motor reaction force
is determined by the external force)
8. In learning process, the buzzer will sound, to alarm the user not touch the
doors, to avoid pinched.
After the learning process is finished, the buzzer will stop sounding.
