Soft Drink Glass Door Display Refrigerator Upright Showcase Refrigerator
US$ 200 - 450
MOQ: 1 Forty-Foot Container
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
SMAD & OEM
Type:
Display Cooler
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Commercial Beverage Showcase Wholesale 420~980LUS$ 280 - 300MOQ: 42 Units -
420-980L Commercial Upright Showcase Glass RefrigeratorsUS$ 250 - 550MOQ: 1 Forty-Foot Container
-
Glass Door Ice Cream Freezer/ Supermarket Display Showcase, Chest FreezerNegotiableMOQ: 1
-
SC-281 Single Door Glass Display Showcase for Beverage China ManufactuerUS$ 50 - 100MOQ: 1 Forty-Foot Container
-
Supermarket Upright SC-198 Single Door Glass Display Showcase for Beverage China ManufactuerUS$ 50 - 100MOQ: 1 Forty-Foot Container
Place of Origin
China
Brand Name
SMAD & OEM
Type
Display Cooler
Style
Double-temperature
Certification
CE
Capacity
200-660
Temperature
-18
Climate Type
N/T
Refrigerant
r134a/r600
Product Show:
Product Description:
| MODEL | LG-200F | LG-228F | LG-250F | LG-268F | LG-300F | LG-350F | LG-430F | LG-660B |
| Net (lt) | 164.55 | 204.59 | 226.99 | 239.67 | 264.78 | 314.92 | 420.45 | 664.72 |
| Cooling system | Fan cooling | Fan cooling | Fan cooling | Fan cooling | Fan cooling | Fan cooling | Fan cooling | Fan cooling |
| Auto-Defrost | Yes | No | Yes | No | Yes | Yes | Yes | Yes |
| Control system | Electronic | Electronic | Electronic | Electronic | Electronic | Electronic | Electronic | Electronic |
| Temperature digital screen | Yes | No | Yes | No | Yes | Yes | Yes | Yes |
| External Dimension WxDxH (mm) | 530x595x1545 | 530*595*1665 | 530x595x1745 | 530*595*1845 | 620x595x1845 | 620x630x1935 | 620x690x2073 | 840x730x2036 |
| Internal Dimension WxDxH (mm) | 450*433*930 | 450*433*1050 | 450*433*1130 | 450*433*1230 | 530*433*1230 | 530x473x1320 | 530*545*1495 | 750*595*1535 |
| Dimensions with packing,carton WxDxH | 585x625x1604 | 585*625*1804 | 585x625x1804 | 585*625*1904 | 685x625x1904 | 685x665x1994 | 685x725x2132 | 895*785*2136 |
| Weight net /Weight gross (kg) | 56/62 | 56/62 | 62/72 | 62/72 | 68/89 | 75/85 | 85/95 | 110/125 |
| 20'GP/ 40' GP/ 40' HQ Container | 45/102/102 | 36/96/96 | 36/77/95 | 27/75/94 | 27/57/75 | 24/54/71or54 | 24/51/51 | 18/39/39 |
| Glass Door type | Right hand hinge door | Right hand hinge door | Right hand hinge door | Right hand hinge door | Right hand hinge door | Right hand hinge door | Right hand hinge door | Right hand hinge door |
| Door frame, door handle material | black/white pvc | black/white pvc | black/white pvc | black/white pvc | black/white pvc | black/white pvc | black/white pvc | Aluminum with silver color or black |
| Height of canopy | 204mm/280mm | 204mm/280mm | 204mm/280mm | 204mm/280mm | 204mm/280mm | 204mm/280mm | 280mm | 280mm |
| Glass type, (low-e coated/tempered)* | TEMPERED GLASS | TEMPERED GLASS | TEMPERED GLASS | TEMPERED GLASS | TEMPERED GLASS | TEMPERED GLASS | TEMPERED GLASS | TEMPERED GLASS |
| Door auto closing | For option | For option | For option | For option | For option | For option | For option | YES |
| foaming agent(insulation) | cyclopentane | cyclopentane | cyclopentane | cyclopentane | cyclopentane | cyclopentane | cyclopentane | cyclopentane |
| Dimensions (mm) | 50(average) | 50(average) | 50(average) | 50(average) | 50(average) | 50(average) | 50(average) | 50(average) |
| Adjustable shelves (pcs) | 3 plastic coating | 3 plastic coating | 4 plastic coating | 4 plastic coating | 4 plastic coating | 4 plastic coating | 4 plastic coating | 4 plastic coating |
| Adjustable feet (pcs),at front | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 0 |
| swivel wheels ,at back | 2 | 0 | 2 | 0 | 2 | 2 | 2 | 4 |
| Internal light vert./hor.*(flourescent ) | Horizontal*1 | Horizontal*1 | Horizontal*1 | Horizontal*1 | Horizontal*1 | Horizontal*1 | Vertical *1 | Vertical *1 |
| Voltage/frequency | 220-240V/50.60HZ | 220-240V/50.60HZ | 220-240V/50,60HZ | 220-240V/50,60HZ | 220-240V/50.60HZ | 220-240V/50.60HZ | 220-240V/50.60HZ | 220-240V/50.60HZ |
| Power consumption (w) | 204 | 204 | 210 | 210 | 255 | 255 | 300 | 460 |
| Amp. Consumption (A) | 1.6 | 1.6 | 1.7 | 1.7 | 1.9 | 1.9 | 2.2 | 3.3 |
| Energy consumption (kWh/24h) | 1.6 | 1.6 | 1.7 | 1.7 | 2.56 | 2.86 | 2.98 | 5.5 |
| Climate Class According to EN441-4 | Class 3 ~ 4 | Class 3 ~ 4 | Class 3 ~ 4 | Class 3 ~ 4 | Class 3 ~ 4 | Class 3 ~ 4 | Class 3 ~ 4 | Class 3 ~ 4 |
| Cabinet Tem. 0C | 0~10 | 0~10 | 0~10 | 0~10 | 0~10 | 0~10 | 0~10 | 0~10 |
| Max. Ambient Temp. 0C | 38 | 38 | 38 | 38 | 38 | 38 | 38 | 38 |
| Refrigerant (CFC-free) gr | R134a /115g | R134a /115g | R134a /130g | R134a /130g | R134a /150g | R134a /160g | R134a /230g | R134a /230g |
| Outer casing, galvanized; pre-painted | Pre-paintedcold-roll steel sheets | Pre-paintedcold-roll steel sheets | Pre-paintedcold-roll steel sheets | Pre-paintedcold-roll steel sheets | Pre-paintedcold-roll steel sheets | Pre-paintedcold-roll steel sheets | Pre-paintedcold-roll steel sheets | Pre-paintedcold-roll steel sheets |
| Cabinet | polyester powder paint Pre-painted aluminium | pre-painted aluminium plate | polyester powder paint Pre-painted aluminium | pre-painted aluminium plate | polyester powder paint Pre-painted aluminium | polyester powder paint Pre-painted aluminium | polyester powder paint Pre-painted aluminium | polyester powder paint Pre-painted aluminium |
| Condenser | compact wire & tube design | compact wire & tube design | compact wire & tube design | compact wire & tube design | compact wire & tube design | compact wire & tube design | Copper fins | Copper fins |
| Condenser fan motor | for option $7 for extra | for option $7 for extra | for option $7 for extra | for option $7 for extra | for option $7 for extra | for option $7 for extra | yes | yes |
| Evaporator | Copper fins | Copper fins | Copper fins | Copper fins | Copper fins | Copper fins | Copper fins | Copper fins |
| Evaporator fan | High speed | High speed | High speed | High speed | High speed | High speed | High speed | High speed |
| canopy logo and side sticker | for option $6 for extra | for option $6 for extra | for option $6 for extra | for option $6 for extra | for option $7 for extra | for option $7for extra | for option $7 for extra | for option $7 for extra |
| Certification | CE,ROHS | CE,ROHS | CE,ROHS | CE,ROHS | CE,ROHS,SASO | CE,ROHS,SASO,MEPS | CE,ROHS | CE,ROHS,SASO |
We have deep freezer ≤-25 °C with different capacity 100/200/300/400/500/600/700/960L for your choices
We offer 2 years for the whole unit and 3 years for main part.
Detailed pictures:
Do the brand, logo, plug and the printing artwork as your requirements.
We offer 2 years for the whole unit and 3 years for main part.
Other models:
More products in our company:
Accept OEM/ODM order, Logo print service, contact us for promotion surprise!
About us:
Qingdao Smad Electric Appliances Co., Ltd. (SMAD) was set up in 2004. After many years of hard work, we have become a normalized and professional enterprise. Now SMAD has a staff of 600 persons and an annual output of 350 million Yuan. The development of SMAD is among the fastest in the field. The production capacity has grown over 100% for 3 years since we were founded. The sales of SMAD have increased doubly year by year.
If you are interested in our product ,pls feel free to contact me !
We welcome you to visit our factory!
FAQ:
Our Markets:
√ North America √ South America √ Western Europe
√ Eastern Europe √ Eastern Asia √ Southeast Asia
√ Middle East √ Africa √ Oceania
